Technical specs - AR 480 T weycor
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 6 t
- Standard tyres
- 16/70-20 MPT 14 PR
- Bucket width
- 2.15 m
- Bucket capacity
- 1 m³
- Bucket capacity min.
- 1 m³
- Steering mode
- KL
- Transport length
- 5.804 m
- Transport width
- 1.95 m
- Transport height
- 2.796 m
- Travel speed
- 20 km/h
- Max. discharge height
- 4.089 m
- Lifting force
- 36 kN
- Model series
- AR
- Engine manuf.
- Deutz
- Engine type
- TD2.9 L4
- Engine power
- 55.4 kW
- Displacement
- 2.9 l
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 260 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 92x110 mm
- Emission level
- V
More technical details, like: bucket capacity max., turning radius outside, dimension lxwxh are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
No
- Swing loader
-
No
- telescopic
-
Yes
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
