AR 400 weycor AR 400 Specifications & Technical Data (2019—2026)

The Weycor AR 400 is a wheel loader manufactured since 2019. It has a weight of 4.55 tons and a transport length of 5.25 meters. T…

The Weycor AR 400 is a wheel loader manufactured since 2019. It has a weight of 4.55 tons and a transport length of 5.25 meters. The bucket capacity is 0.85 cubic meters with a width of 1.85 meters. The maximum discharge height is 2.475 meters. It has a travel speed of 20 km/h and a transport width of 1.785 meters. The transport height is also 2.475 meters. The lifting force of this machine is 46.5 kN. It has a turning radius outside of 4.17 meters. The minimum bucket capacity is 0.85 cubic meters.

Visit weycor live at

AR 400

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - AR 400 weycor

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.55 t

Standard tyres: 12.5-18 MPT

Bucket width: 1.85 m

Bucket capacity: 0.85 m³

Bucket capacity min.: 0.85 m³

Steering mode: KL

Transport length: 5.25 m

Transport width: 1.785 m

Transport height: 2.475 m

Travel speed: 20 km/h

Max. discharge height: 2.475 m

Turning radius outside: 4.17 m

Lifting force: 46.5 kN

Model series: AR

Engine manuf.: Yanmar

Engine type: 4TNV86CHT

Engine power: 46 kW

Displacement: 2.091 l

Revolutions at max torque: 2300 rpm

Max. torque: 198/1690 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: bucket capacity max., dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

weycor AR 400 FAQ

When was the weycor AR 400 manufactured?

The weycor AR 400 was first produced in 2019.

How much does the weycor AR 400 wheel loader weigh?

The weycor AR 400 wheel loader weighs 4.55 tons.

What are the transport dimensions of the weycor AR 400 wheel loader?

The weycor AR 400 has a transport length of 5.25 meters, a transport width of 1.79 meters, and a transport height of 2.48 meters.

What is the travel speed of the weycor AR 400 wheel loader?

The weycor AR 400 has a travel speed of 20 km/h.

What is the standard tyre size of the weycor AR 400?

The weycor AR 400 has standard tyres sized 12.5-18 MPT.

What are the maneuverability specifications of the weycor AR 400 wheel loader?

The weycor AR 400 wheel loader has an articulated-frame steering mode and an outside turning radius of 4.17 meters.

What is the lifting force of the weycor AR 400 wheel loader?

The weycor AR 400 wheel loader has a lifting force of 46.5 kN. No power rating data is available for this model in the provided source.

What is the maximum discharge height of the weycor AR 400?

The weycor AR 400 has a maximum discharge height of 2.48 meters.

What are the specifications of the bucket on the weycor AR 400 wheel loader?

The bucket of the weycor AR 400 has a capacity of 0.85 cubic meters, a minimum capacity of 0.85 cubic meters, and a width of 1.85 meters.

How much is a weycor AR 400 Wheel loader (2019u20132025) worth?

The residual value of the weycor AR 400 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
