9580 T Weidemann 9580 T Specifications & Technical Data (2019—2026)

The Weidemann 9580 T is a wheel loader manufactured since 2019. It has a weight of 11.207 tons and a transport length of 6.96 mete…

The Weidemann 9580 T is a wheel loader manufactured since 2019. It has a weight of 11.207 tons and a transport length of 6.96 meters. The maximum discharge height is 3.44 meters and it can travel at a speed of 20 km/h. The transport width is 2.39 meters and the transport height is 3.11 meters. The turning radius outside is 5.77 meters. Special equipment includes a diesel particulate filter, quick hitch hydraulic, and telescopic features.

9580 T

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 9580 T Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 11.207 t

Standard tyres: 500/70 R24 Michelin XMCL ET40

Steering mode: KL

Transport length: 6.96 m

Transport width: 2.39 m

Transport height: 3.11 m

Travel speed: 20 km/h

Max. discharge height: 3.44 m

Turning radius outside: 5.77 m

Model series: T

Engine manuf.: Deutz

Engine type: TCD3.6 S5

Engine power: 100 kW

Displacement: 3.621 l

Revolutions at max torque: 2300 rpm

No. of cylinders: 4

Emission level: V

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., lifting force, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Weidemann 9580 T FAQ

When was the Weidemann 9580 T manufactured?

The Weidemann 9580 T was first produced in 2019.

How much does the Weidemann 9580 T weigh?

The Weidemann 9580 T weighs 11.21 tons.

What are the transport dimensions of the Weidemann 9580 T wheel loader?

The Weidemann 9580 T has a transport length of 6.96 meters, a transport width of 2.39 meters, and a transport height of 3.11 meters.

What is the travel speed of the Weidemann 9580 T wheel loader?

The Weidemann 9580 T has a travel speed of 20 km/h.

What are the standard tyre specifications for the Weidemann 9580 T wheel loader?

The Weidemann 9580 T comes equipped with standard tyres sized 500/70 R24 Michelin XMCL ET40.

What are the maneuverability specifications of the Weidemann 9580 T wheel loader?

The Weidemann 9580 T wheel loader has an articulated-frame steering system and an outside turning radius of 5.77 meters.

What is the maximum discharge height of the Weidemann 9580 T wheel loader?

The Weidemann 9580 T has a maximum discharge height of 3.44 meters.

How much is a Weidemann 9580 T Wheel loader (2019u20132025) worth?

The residual value of the Weidemann 9580 T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
