9080 Weidemann 9080 Specifications & Technical Data (2019—2024)

The Weidemann 9080 is a wheel loader manufactured since 2019. With a weight of 10.72 tons, it has a transport length of 7.06 meter…

The Weidemann 9080 is a wheel loader manufactured since 2019. With a weight of 10.72 tons, it has a transport length of 7.06 meters and a transport width of 2.39 meters. The machine stands at a transport height of 3.11 meters and has a turning radius outside of 5.63 meters. It is equipped with a diesel particulate filter and features quick hitch hydr. and telescopic capabilities. The wheel loader can reach a maximum discharge height of 3.3 meters and has a travel speed of 20 km/h.

9080

Years of manufacture: 2019—2024

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 9080 Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 10.72 t

Standard tyres: 500/70 R24 Michelin XMCL ET40

Steering mode: KL

Transport length: 7.06 m

Transport width: 2.39 m

Transport height: 3.11 m

Travel speed: 20 km/h

Max. discharge height: 3.3 m

Turning radius outside: 5.63 m

Engine manuf.: Deutz

Engine type: TCD4.1 S5

Engine power: 115 kW

Displacement: 4.038 l

Revolutions at max torque: 2300 rpm

No. of cylinders: 4

Emission level: V

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., lifting force, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Weidemann 9080 FAQ

When was the Weidemann 9080 manufactured?

The Weidemann 9080 was manufactured from 2019 to 2024.

How much does the Weidemann 9080 weigh?

The Weidemann 9080 weighs 10.72 tons.

What are the transport dimensions of the Weidemann 9080 wheel loader?

The Weidemann 9080 has a transport length of 7.06 meters, a transport width of 2.39 meters, and a transport height of 3.11 meters.

What is the travel speed of the Weidemann 9080 wheel loader?

The Weidemann 9080 has a travel speed of 20 km/h.

What are the standard tyre specifications for the Weidemann 9080?

The Weidemann 9080 is equipped with standard tyres sized 500/70 R24 Michelin XMCL ET40.

What are the maneuverability specifications of the Weidemann 9080 wheel loader?

The Weidemann 9080 has an articulated-frame steering mode and an outside turning radius of 5.63 meters.

What is the maximum discharge height of the Weidemann 9080 wheel loader?

The Weidemann 9080 has a maximum discharge height of 3.3 meters.

How much is a Weidemann 9080 Wheel loader (2019u20132024) worth?

The residual value of the Weidemann 9080 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
