2070 CX 50 LP Weidemann 2070 CX 50 LP Specifications & Technical Data (2006—2008)

The Weidemann 2070 CX 50 LP is a wheel loader manufactured by Weidemann from 2006 to 2008. It has a weight of 3.13 tons and a tran…

The Weidemann 2070 CX 50 LP is a wheel loader manufactured by Weidemann from 2006 to 2008. It has a weight of 3.13 tons and a transport length of 4.13 meters. The bucket capacity is 0.45 cubic meters, with a minimum capacity of 0.45 cubic meters. The transport width is 1.41 meters and the transport height is 1.79 meters. The special equipment included is a quick hitch mechanism.

2070 CX 50 LP

Years of manufacture: 2006—2008

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 2070 CX 50 LP Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.13 t

Standard tyres: 11.5/80-15.3AS

Bucket capacity: 0.45 m³

Bucket capacity min.: 0.45 m³

Steering mode: KL

Transport length: 4.13 m

Transport width: 1.41 m

Transport height: 1.79 m

Model series: CX

Engine manuf.: Perkins

Engine type: 404C-22

Engine power: 35 kW

More technical details, like: bucket width, bucket capacity max., travel speed, max. discharge height, turning radius outside, lifting force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

2070 CX 50 LP Weidemann Specification for North America (EN)

Weidemann 2070 CX 50 LP FAQ

When was the Weidemann 2070 CX 50 LP manufactured?

The Weidemann 2070 CX 50 LP was manufactured from 2006 to 2008.

How much does the Weidemann 2070 CX 50 LP weigh?

The Weidemann 2070 CX 50 LP weighs 3.13 tons.

What are the transport dimensions of the Weidemann 2070 CX 50 LP wheel loader?

The Weidemann 2070 CX 50 LP has a transport length of 4.13 meters, a transport width of 1.41 meters, and a transport height of 1.79 meters.

What are the undercarriage specifications of the Weidemann 2070 CX 50 LP?

The Weidemann 2070 CX 50 LP is equipped with standard tyres sized 11.5/80-15.3AS.

What is the steering mode of the Weidemann 2070 CX 50 LP?

The Weidemann 2070 CX 50 LP has articulated-frame steering.

What is the bucket capacity of the Weidemann 2070 CX 50 LP wheel loader?

The Weidemann 2070 CX 50 LP wheel loader has a bucket capacity of 0.45 cubic meters.
