WL60 Wacker Neuson WL60 Specifications & Technical Data (2015—2018)

The Wacker Neuson WL60 is a wheel loader manufactured from 2015 to 2018. It has a weight of 5.9 tons and a transport length of 4.7…

The Wacker Neuson WL60 is a wheel loader manufactured from 2015 to 2018. It has a weight of 5.9 tons and a transport length of 4.78 meters. The bucket capacity is 0.95 cubic meters, with a bucket width of 2 meters. The maximum discharge height is 2.841 meters, and it has a travel speed of 20 km/h. The transport width is 1.829 meters, and the transport height is 2.693 meters. The turning radius outside is 3.686 meters. Special equipment includes a quick hitch hydraulic mechanism.

Visit Wacker Neuson live at

WL60

Years of manufacture: 2015—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - WL60 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.9 t

Standard tyres: 405/70 R 18 EM ET 0

Bucket width: 2 m

Bucket capacity: 0.95 m³

Bucket capacity min.: 0.95 m³

Steering mode: KL

Transport length: 4.78 m

Transport width: 1.829 m

Transport height: 2.693 m

Travel speed: 20 km/h

Max. discharge height: 2.841 m

Turning radius outside: 3.686 m

Model series: WL

Engine manuf.: Perkins

Engine type: 854E-E34TAWF

Engine power: 75 kW

Displacement: 3.4 l

Revolutions at max torque: 2500 rpm

Emission level: III B

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Wacker Neuson WL60 FAQ

When was the Wacker Neuson WL60 manufactured?

The Wacker Neuson WL60 was manufactured from 2015 to 2018.

How much does the Wacker Neuson WL60 weigh?

The Wacker Neuson WL60 weighs 5.9 tons.

What are the transport dimensions of the Wacker Neuson WL60 wheel loader?

The Wacker Neuson WL60 has a transport length of 4.78 meters, a transport width of 1.83 meters, and a transport height of 2.69 meters.

What is the travel speed of the Wacker Neuson WL60 wheel loader?

The Wacker Neuson WL60 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Wacker Neuson WL60?

The Wacker Neuson WL60 is equipped with standard tyres sized 405/70 R 18 EM ET 0.

What are the maneuverability specifications of the Wacker Neuson WL60 wheel loader?

The Wacker Neuson WL60 has an articulated-frame steering system and an outside turning radius of 3.686 meters.

What is the maximum discharge height of the Wacker Neuson WL60 wheel loader?

The Wacker Neuson WL60 has a maximum discharge height of 2.84 meters.

What are the bucket specifications of the Wacker Neuson WL60 wheel loader?

The Wacker Neuson WL60 has a bucket capacity of 0.95 cubic meters, a minimum bucket capacity of 0.95 cubic meters, and a bucket width of 2 meters.

How much is a Wacker Neuson WL60 Wheel loader (2015u20132018) worth?

The residual value of the Wacker Neuson WL60 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
