3448 H Thaler 3448 H Specifications & Technical Data (2020—2026)

The Thaler 3448 H is a wheel loader manufactured by Thaler since 2020. It has a weight of 2.49 tons and a transport length of 4.2 …

The Thaler 3448 H is a wheel loader manufactured by Thaler since 2020. It has a weight of 2.49 tons and a transport length of 4.2 meters. The maximum discharge height is 3.11 meters and it has a travel speed of 20 km/h. The transport width is 1.16 meters and the transport height is 2.27 meters. The turning radius outside is 2.382 meters. It is equipped with a quick hitch hydr.

3448 H

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 3448 H Thaler

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.49 t

Standard tyres: 10.0/75-15.3 AS

Steering mode: KL

Transport length: 4.2 m

Transport width: 1.16 m

Transport height: 2.27 m

Travel speed: 20 km/h

Max. discharge height: 3.11 m

Turning radius outside: 2.382 m

Engine manuf.: Yanmar

Engine type: k.A.

Engine power: 35.4 kW

Displacement: 2.22 l

Revolutions at max torque: 3000 rpm

No. of cylinders: 4

Emission level: V

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Thaler 3448 H FAQ

When was the Thaler 3448 H manufactured?

The Thaler 3448 H was first produced in 2020.

How much does the Thaler 3448 H wheel loader weigh?

The Thaler 3448 H wheel loader weighs 2.49 tons.

What are the transport dimensions of the Thaler 3448 H wheel loader?

The Thaler 3448 H has a transport length of 4.2 meters, a transport width of 1.16 meters, and a transport height of 2.27 meters.

What is the travel speed of the Thaler 3448 H wheel loader?

The Thaler 3448 H has a travel speed of 20 km/h.

What are the undercarriage tyre specifications of the Thaler 3448 H wheel loader?

The Thaler 3448 H wheel loader is equipped with standard tyres sized 10.0/75-15.3 AS.

What are the maneuverability specifications of the Thaler 3448 H wheel loader?

The Thaler 3448 H has an articulated-frame steering system and an outside turning radius of 2.382 meters.

What is the material handling capacity of the Thaler 3448 H in terms of discharge height?

The Thaler 3448 H has a maximum discharge height of 3.11 meters.

How much is a Thaler 3448 H Wheel loader (2020u20132025) worth?

The residual value of the Thaler 3448 H depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
