SKL 863 Terex-Schaeff SKL 863 Specifications & Technical Data (1998—2004)

The Terex-Schaeff SKL 863 is a wheel loader manufactured from 1998 to 2004. It has a weight of 8.1 tons and a transport length of …

The Terex-Schaeff SKL 863 is a wheel loader manufactured from 1998 to 2004. It has a weight of 8.1 tons and a transport length of 5.973 meters. The bucket capacity is 2.4 cubic meters with a width of 2.2 meters. The maximum discharge height is 2.75 meters and it has a travel speed of 20 km/h. The transport width is 2.2 meters and the transport height is 2.96 meters. It has a lifting force of 82.68 kN and a turning radius outside of 4.9 meters. The bucket capacity minimum is 2.4 cubic meters. It is equipped with a quick hitch mechanism.

SKL 863

Years of manufacture: 1998—2004

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - SKL 863 Terex-Schaeff

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.1 t

Standard tyres: 405/80 R 25

Bucket width: 2.2 m

Bucket capacity: 2.4 m³

Bucket capacity min.: 2.4 m³

Steering mode: KL

Transport length: 5.973 m

Transport width: 2.2 m

Transport height: 2.96 m

Travel speed: 20 km/h

Max. discharge height: 2.75 m

Turning radius outside: 4.9 m

Lifting force: 82.68 kN

Model series: SKL

Engine manuf.: Perkins

Engine type: 1004.4

Engine power: 74 kW

Displacement: 4 l

Revolutions at max torque: 2200 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

SKL 863 Terex-Schaeff Specification for Europe (DE)

Terex-Schaeff SKL 863 FAQ

When was the Terex-Schaeff SKL 863 manufactured?

The Terex-Schaeff SKL 863 was manufactured from 1998 to 2004.

How much does the Terex-Schaeff SKL 863 weigh?

The Terex-Schaeff SKL 863 weighs 8.1 tons.

What are the transport dimensions of the Terex-Schaeff SKL 863 wheel loader?

The Terex-Schaeff SKL 863 has a transport length of 5.97 meters, a transport width of 2.2 meters, and a transport height of 2.96 meters.

What is the travel speed of the Terex-Schaeff SKL 863 wheel loader?

The Terex-Schaeff SKL 863 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Terex-Schaeff SKL 863?

The Terex-Schaeff SKL 863 is equipped with standard tyres sized 405/80 R 25.

What are the maneuverability specifications of the Terex-Schaeff SKL 863 wheel loader?

The Terex-Schaeff SKL 863 has an articulated-frame steering mode and an outside turning radius of 4.9 meters.

What is the power rating of the Terex-Schaeff SKL 863 wheel loader?

The source data does not provide a power rating for the Terex-Schaeff SKL 863 wheel loader.

What is the material handling capacity of the Terex-Schaeff SKL 863 in terms of discharge height?

The Terex-Schaeff SKL 863 has a maximum discharge height of 2.75 meters.

What are the specifications of the bucket on the Terex-Schaeff SKL 863 wheel loader?

The Terex-Schaeff SKL 863 wheel loader has a bucket capacity of 2.4 cubic meters and a bucket width of 2.2 meters.

How much is a Terex-Schaeff SKL 863 Wheel loader (1998u20132004) worth?

The residual value of the Terex-Schaeff SKL 863 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
