830-2 TCM 830-2 Specifications & Technical Data (1989—2024)

The TCM 830-2 is a wheel loader manufactured since 1989. It has a weight of 6 tons and a bucket capacity of 1 cubic meter, with a …

The TCM 830-2 is a wheel loader manufactured since 1989. It has a weight of 6 tons and a bucket capacity of 1 cubic meter, with a bucket width of 2 meters. The maximum discharge height is 2 meters, and it has a travel speed of 34 km/h. The transport width is 2 meters, and the transport height is 3 meters. The turning radius outside is 4 meters. Special equipment includes air conditioning.

Wheel Loaders TCM 830-2

Technical specs - 830-2 TCM

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.94 t
Bucket width
2.18 m
Bucket capacity
1.6 m³
Bucket capacity max.
1.6 m³
Transport width
2.12 m
Transport height
3.11 m
Travel speed
34.8 km/h
Max. discharge height
2.7 m
Turning radius outside
4.98 m
Engine manuf.
Isuzu
Engine type
6BBI
Engine power
64.7 kW
Displacement
5.393 l

More technical details, like: standard tyres, bucket capacity min., steering mode, transport length, lifting force, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

TCM 830-2 FAQ

When was the TCM 830-2 manufactured?

The TCM 830-2 was manufactured from 1989 to 2024.

How much does the TCM 830-2 wheel loader weigh?

The TCM 830-2 wheel loader weighs 6.94 tons.

What are the transport dimensions of the TCM 830-2 wheel loader?

The TCM 830-2 has a transport width of 2.12 meters and a transport height of 3.11 meters.

What is the travel speed of the TCM 830-2 wheel loader?

The TCM 830-2 wheel loader has a travel speed of 34.8 km/h.

What is the turning radius of the TCM 830-2 wheel loader?

The TCM 830-2 wheel loader has an outside turning radius of 4.98 meters.

What is the maximum discharge height of the TCM 830-2?

The TCM 830-2 has a maximum discharge height of 2.7 meters.

What are the bucket specifications of the TCM 830-2 wheel loader?

The TCM 830-2 wheel loader has a bucket capacity of 1.6 cubic meters and a bucket width of 2.18 meters.
