655D SEM 655D Specifications & Technical Data (2026—2026)

Weight: 17.022t – Standard tyres: 23.5-25 PR16 – Bucket width: 2.963m – Bucket capacity min.: 2.7m³ – Bucket capacity max.: 4.5m³ – Steering mode: KL

Wheel Loaders SEM 655D

Technical specs - 655D SEM

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
17.022 t
Standard tyres
23.5-25 PR16
Bucket width
2.963 m
Bucket capacity min.
2.7 m³
Bucket capacity max.
4.5 m³
Steering mode
KL
Transport length
8.085 m
Transport width
2.87 m
Transport height
3.463 m
Travel speed
39 km/h
Max. discharge height
3.058 m
Model series
D
Engine manuf.
Weichai
Engine type
WD10G
Engine power
162 kW
Displacement
9.7 l
Emission level
Tier 2 / Stage II

More technical details, like: bucket capacity, turning radius outside, lifting force, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
