8620 T Schäffer 8620 T Specifications & Technical Data (2016—2021)

The Schäffer 8620 T is a wheel loader manufactured from 2016 to 2021. It has a weight of 6.5 tons and a transport length of 6.04 m…

The Schäffer 8620 T is a wheel loader manufactured from 2016 to 2021. It has a weight of 6.5 tons and a transport length of 6.04 meters. The maximum discharge height is 4.19 meters and it can travel at a speed of 20 km/h. The transport width is 1.85 meters and the transport height is 2.5 meters. It has a lifting force of 41.19 kN and a turning radius outside of 4.35 meters. Special equipment includes a telescopic feature.

8620 T

Years of manufacture: 2016—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 8620 T Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.5 t

Standard tyres: 405/70-20

Steering mode: KL

Transport length: 6.04 m

Transport width: 1.85 m

Transport height: 2.5 m

Travel speed: 20 km/h

Max. discharge height: 4.19 m

Turning radius outside: 4.35 m

Lifting force: 41.19 kN

Engine manuf.: Deutz

Engine type: N/A

Engine power: 75 kW

Displacement: 3.6 l

No. of cylinders: 4

Emission level: Tier 4 f

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 8620 T FAQ

When was the Schu00e4ffer 8620 T manufactured?

The Schu00e4ffer 8620 T was manufactured from 2016 to 2021.

How much does the Schu00e4ffer 8620 T wheel loader weigh?

The Schu00e4ffer 8620 T wheel loader weighs 6.5 tons.

What are the transport dimensions of the Schu00e4ffer 8620 T wheel loader?

The Schu00e4ffer 8620 T has a transport length of 6.04 meters, a transport width of 1.85 meters, and a transport height of 2.5 meters.

What is the travel speed of the Schu00e4ffer 8620 T wheel loader?

The Schu00e4ffer 8620 T has a travel speed of 20 km/h.

What are the standard tyre specifications for the Schu00e4ffer 8620 T wheel loader?

The Schu00e4ffer 8620 T wheel loader comes with standard tyres sized 405/70-20.

What are the maneuverability specifications of the Schu00e4ffer 8620 T wheel loader?

The Schu00e4ffer 8620 T has an articulated-frame steering mode and an outside turning radius of 4.35 meters.

What are the power ratings of the Schu00e4ffer 8620 T wheel loader?

There is no power rating data available for the Schu00e4ffer 8620 T wheel loader in the provided information.

What is the maximum discharge height of the Schu00e4ffer 8620 T?

The Schu00e4ffer 8620 T has a maximum discharge height of 4.19 meters.

How much is a Schu00e4ffer 8620 T Wheel loader (2016u20132021) worth?

The residual value of the Schu00e4ffer 8620 T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
