Technical specs - 6680 T-3 Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.3 t

Standard tyres: 400/70-20 AS, ET0

Steering mode: KL

Transport length: 5.78 m

Transport width: 2.07 m

Transport height: 2.63 m

Travel speed: 20 km/h

Max. discharge height: 3.98 m

Turning radius outside: 4.4 m

Engine manuf.: Deutz

Engine type: TCD2.9

Engine power: 55 kW

Displacement: 2.9 l

No. of cylinders: 4

Emission level: V

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., lifting force, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 6680 T-3 FAQ

When was the Schu00e4ffer 6680 T-3 manufactured?

The Schu00e4ffer 6680 T-3 was first produced in 2025.

How much does the Schu00e4ffer 6680 T-3 wheel loader weigh?

The Schu00e4ffer 6680 T-3 wheel loader weighs 6.3 tons.

What are the transport dimensions of the Schu00e4ffer 6680 T-3 wheel loader?

The Schu00e4ffer 6680 T-3 has a transport length of 5.78 meters, a transport width of 2.07 meters, and a transport height of 2.63 meters.

What is the travel speed of the Schu00e4ffer 6680 T-3 wheel loader?

The Schu00e4ffer 6680 T-3 has a travel speed of 20 km/h.

What are the standard tyre specifications for the Schu00e4ffer 6680 T-3's undercarriage?

The Schu00e4ffer 6680 T-3 is equipped with standard tyres sized 400/70-20 AS, ET0 on its undercarriage.

What are the maneuverability specifications of the Schu00e4ffer 6680 T-3 wheel loader?

The Schu00e4ffer 6680 T-3 has an articulated-frame steering system and an outside turning radius of 4.4 meters.

What is the maximum discharge height of the Schu00e4ffer 6680 T-3 wheel loader?

The Schu00e4ffer 6680 T-3 wheel loader has a maximum discharge height of 3.98 meters.

How much is a Schu00e4ffer 6680 T-3 Wheel loader (2025u20132025) worth?

The residual value of the Schu00e4ffer 6680 T-3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
