2445 Schäffer 2445 Specifications & Technical Data (2016—2019)

The Schäffer 2445 is a wheel loader manufactured from 2016 to 2019. It has a weight of 2.65 tons and a transport length of 4.045 m…

The Schäffer 2445 is a wheel loader manufactured from 2016 to 2019. It has a weight of 2.65 tons and a transport length of 4.045 meters. The bucket capacity is 0.5 cubic meters with a width of 1.3 meters. The maximum discharge height is 1.7 meters and it has a travel speed of 20 km/h. The transport width is 1.02 meters and the transport height is 2.211 meters. The turning radius outside is 2.45 meters. The minimum bucket capacity is also 0.5 cubic meters.

2445

Years of manufacture: 2016—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 2445 Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.65 t

Standard tyres: 10.0/75-15.3 AS

Bucket width: 1.3 m

Bucket capacity: 0.5 m³

Bucket capacity min.: 0.5 m³

Steering mode: KL

Transport length: 4.045 m

Transport width: 1.02 m

Transport height: 2.211 m

Travel speed: 20 km/h

Max. discharge height: 1.7 m

Turning radius outside: 2.45 m

Engine manuf.: Kubota

Engine type: N/A

Engine power: 33 kW

No. of cylinders: 4

More technical details, like: bucket capacity max., lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

2445 Schäffer Specification for Europe (DE)

Schäffer 2445 FAQ

When was the Schu00e4ffer 2445 manufactured?

The Schu00e4ffer 2445 was manufactured from 2016 to 2019.

How much does the Schu00e4ffer 2445 wheel loader weigh?

The Schu00e4ffer 2445 wheel loader weighs 2.65 tons.

What are the transport dimensions of the Schu00e4ffer 2445 wheel loader?

The Schu00e4ffer 2445 has a transport length of 4.05 meters, a transport width of 1.02 meters, and a transport height of 2.21 meters.

What is the travel speed of the Schu00e4ffer 2445 wheel loader?

The Schu00e4ffer 2445 wheel loader has a travel speed of 20 km/h.

What are the undercarriage tyre specifications of the Schu00e4ffer 2445 wheel loader?

The Schu00e4ffer 2445 wheel loader is equipped with standard tyres sized 10.0/75-15.3 AS.

What are the maneuverability specifications of the Schu00e4ffer 2445 wheel loader?

The Schu00e4ffer 2445 wheel loader has an outside turning radius of 2.45 meters and uses articulated-frame steering.

What is the maximum discharge height of the Schu00e4ffer 2445 wheel loader?

The Schu00e4ffer 2445 wheel loader has a maximum discharge height of 1.7 meters.

What are the specifications of the primary work tool bucket on the Schu00e4ffer 2445 wheel loader?

The primary work tool bucket on the Schu00e4ffer 2445 has a capacity of 0.5 cubic meters, a minimum capacity of 0.5 cubic meters, and a width of 1.3 meters.

How much is a Schu00e4ffer 2445 Wheel loader (2016u20132019) worth?

The residual value of the Schu00e4ffer 2445 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
