2430 SLT Schäffer 2430 SLT Specifications & Technical Data (2021—2026)

The Schäffer 2430 SLT is a wheel loader manufactured since 2021. It has a weight of 2.555 tons and a transport length of 3.4 meter…

The Schäffer 2430 SLT is a wheel loader manufactured since 2021. It has a weight of 2.555 tons and a transport length of 3.4 meters. The bucket capacity is 0.42 cubic meters with a width of 1.1 meters. The maximum discharge height is 1.7 meters, and it can travel at a speed of 20 km/h. The transport width is 1.3 meters, and the transport height is 1.96 meters. It has a lifting force of 18.63 kN and a turning radius outside of 2.96 meters.

2430 SLT

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 2430 SLT Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.56 t

Standard tyres: 10.0/75-15.3 AS

Bucket width: 1.1 m

Bucket capacity: 0.42 m³

Steering mode: KL

Transport length: 3.4 m

Transport width: 1.3 m

Transport height: 1.96 m

Travel speed: 20 km/h

Max. discharge height: 1.7 m

Turning radius outside: 2.96 m

Lifting force: 18.63 kN

Engine manuf.: Kubota

Engine type: D1703-M-DI

Engine power: 18.5 kW

Displacement: 1.647 l

Revolutions at max torque: 2400 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 2430 SLT FAQ

When was the Schu00e4ffer 2430 SLT manufactured?

The Schu00e4ffer 2430 SLT was first produced in 2021.

How much does the Schu00e4ffer 2430 SLT wheel loader weigh?

The Schu00e4ffer 2430 SLT wheel loader weighs 2.56 tons.

What are the transport dimensions of the Schu00e4ffer 2430 SLT wheel loader?

The Schu00e4ffer 2430 SLT has a transport length of 3.4 meters, a transport width of 1.3 meters, and a transport height of 1.96 meters.

What is the travel speed of the Schu00e4ffer 2430 SLT wheel loader?

The Schu00e4ffer 2430 SLT has a travel speed of 20 km/h.

What are the undercarriage specifications of the Schu00e4ffer 2430 SLT wheel loader?

The Schu00e4ffer 2430 SLT wheel loader is equipped with standard tyres sized 10.0/75-15.3 AS.

What are the maneuverability specifications of the Schu00e4ffer 2430 SLT wheel loader?

The Schu00e4ffer 2430 SLT has an articulated-frame steering system and an outside turning radius of 2.96 meters.

What is the lifting force of the Schu0000e4ffer 2430 SLT?

The Schu0000e4ffer 2430 SLT has a lifting force of 18.63 kN. No power rating data is available for this machine.

What is the material handling capacity of the Schu00e4ffer 2430 SLT in terms of discharge height?

The Schu00e4ffer 2430 SLT has a maximum discharge height of 1.7 meters.

What are the bucket specifications of the Schu00e4ffer 2430 SLT wheel loader?

The Schu00e4ffer 2430 SLT has a bucket capacity of 0.42 cubic meters and a bucket width of 1.1 meters.
