Schäffer 2430-2
- Weight:
- 2.32 t
- Standard tyres:
- 10.0/75-15.3 MPT, ET-40
- Steering mode:
- KL
- Transport length:
- 4.23 m
Schäffer 2430-2 Specifications & Technical Data (2025-2025)
Technical specs - 2430-2 Schäffer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.32 t
- Standard tyres
- 10.0/75-15.3 MPT, ET-40
- Steering mode
- KL
- Transport length
- 4.23 m
- Transport width
- 1.37 m
- Transport height
- 2.23 m
- Travel speed
- 20 km/h
- Max. discharge height
- 1.6 m
- Turning radius outside
- 2.54 m
- Engine manuf.
- Kubota
- Engine type
- D1703-M-DI
- Engine power
- 18.5 kW
- Displacement
- 1.647 l
- Revolutions at max torque
- 2400 rpm
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., lifting force, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
No
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
