2345 T Schäffer 2345 T Specifications & Technical Data (2019—2021)

The Schäffer 2345 T is a wheel loader manufactured from 2019 to 2021. It has a weight of 2.85 tons and a transport length of 3.75 …

The Schäffer 2345 T is a wheel loader manufactured from 2019 to 2021. It has a weight of 2.85 tons and a transport length of 3.75 meters. The maximum discharge height is 1.45 meters, and it can travel at a speed of 20 km/h. The transport width is 0.94 meters, and the transport height is 2.09 meters. It has a lifting force of 18.63 kN and a turning radius outside of 2.19 meters. Special equipment includes a telescopic feature.

2345 T

Years of manufacture: 2019—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 2345 T Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.85 t

Standard tyres: 10.0/75-15.3 AS

Steering mode: KL

Transport length: 3.75 m

Transport width: 0.94 m

Transport height: 2.09 m

Travel speed: 20 km/h

Max. discharge height: 1.45 m

Turning radius outside: 2.19 m

Lifting force: 18.63 kN

Engine manuf.: Kubota

Engine type: N/A

Engine power: 33 kW

No. of cylinders: 4

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 2345 T FAQ

When was the Schu00e4ffer 2345 T manufactured?

The Schu00e4ffer 2345 T was manufactured from 2019 to 2021.

How much does the Schu00e4ffer 2345 T wheel loader weigh?

The Schu00e4ffer 2345 T wheel loader weighs 2.85 tons.

What are the transport dimensions of the Schu00e4ffer 2345 T wheel loader?

The Schu00e4ffer 2345 T has a transport length of 3.75 meters, a transport width of 0.94 meters, and a transport height of 2.09 meters.

What is the travel speed of the Schu00e4ffer 2345 T wheel loader?

The Schu00e4ffer 2345 T has a travel speed of 20 km/h.

What are the standard tyre specifications for the Schu00e4ffer 2345 T wheel loader?

The Schu00e4ffer 2345 T wheel loader comes equipped with standard tyres sized 10.0/75-15.3 AS.

What are the maneuverability specifications of the Schu00e4ffer 2345 T wheel loader?

The Schu00e4ffer 2345 T has an articulated-frame steering mode and an outside turning radius of 2.19 meters.

What is the lifting force of the Schu0000e4ffer 2345 T wheel loader?

The Schu0000e4ffer 2345 T wheel loader has a lifting force of 18.63 kN.

What is the material handling capacity of the Schu00e4ffer 2345 T in terms of maximum discharge height?

The Schu00e4ffer 2345 T has a maximum discharge height of 1.45 meters for material handling.

How much is a Schu00e4ffer 2345 T Wheel loader (2019u20132021) worth?

The residual value of the Schu00e4ffer 2345 T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
