X24-26V Pitbull X24-26V Specifications & Technical Data (2020—2026)
.png)
.png)
Technical specs - X24-26V Pitbull
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.4 t
- Standard tyres
- 400/50-15
- Steering mode
- KL
- Transport length
- 3.25 m
- Transport width
- 1.375 m
- Transport height
- 2.225 m
- Travel speed
- 25 km/h
- Max. discharge height
- 1.9 m
- Turning radius outside
- 6.1 m
- Lifting force
- 17.65 kN
- Model series
- X
- Engine manuf.
- Kubota
- Engine type
- V1505
- Engine power
- 19 kW
- Displacement
- 1.498 l
- Revolutions at max torque
- 1700 rpm
- Max. torque
- 93 Nm
- No. of cylinders
- 4
- Emission level
- V
More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
No
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
