PT 72 Palazzani PT 72 Specifications & Technical Data (2009—2014)

The Palazzani PT 72 is a telescopic wheel loader manufactured by Palazzani from 2009 to 2014. It has a weight of 7.5 tons and a tr…

The Palazzani PT 72 is a telescopic wheel loader manufactured by Palazzani from 2009 to 2014. It has a weight of 7.5 tons and a transport length of 6.17 meters. The bucket capacity is 1.1 cubic meters, with a width of 2 meters. The maximum discharge height is 4.725 meters. It has a travel speed of 33 km/h and a transport width of 2 meters. The transport height is 2.85 meters and the turning radius outside is 5.39 meters. The PT 72 is equipped with a telescopic feature.

PT 72

Years of manufacture: 2009—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PT 72 Palazzani

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.5 t

Standard tyres: 16/70x24

Bucket width: 2 m

Bucket capacity: 1.1 m³

Bucket capacity min.: 1.1 m³

Steering mode: KL

Transport length: 6.17 m

Transport width: 2 m

Transport height: 2.85 m

Travel speed: 33 km/h

Max. discharge height: 4.725 m

Turning radius outside: 5.39 m

Model series: PT

Engine manuf.: Perkins

Engine type: 1104D-44T

Engine power: 73.5 kW

Displacement: 4.4 l

Revolutions at max torque: 2200 rpm

More technical details, like: bucket capacity max., lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Palazzani PT 72 FAQ

When was the Palazzani PT 72 manufactured?

The Palazzani PT 72 was manufactured from 2009 to 2014.

How much does the Palazzani PT 72 wheel loader weigh?

The Palazzani PT 72 wheel loader weighs 7.5 tons.

What are the transport dimensions of the Palazzani PT 72 wheel loader?

The Palazzani PT 72 has a transport length of 6.17 meters, a transport width of 2 meters, and a transport height of 2.85 meters.

What is the travel speed of the Palazzani PT 72 wheel loader?

The Palazzani PT 72 has a travel speed of 33 km/h.

What are the undercarriage specifications of the Palazzani PT 72 wheel loader?

The Palazzani PT 72 wheel loader is equipped with standard tyres sized 16/70x24.

What are the maneuverability specifications of the Palazzani PT 72 wheel loader?

The Palazzani PT 72 has an articulated-frame steering system and an outside turning radius of 5.39 meters.

What is the maximum discharge height of the Palazzani PT 72 wheel loader?

The Palazzani PT 72 wheel loader has a maximum discharge height of 4.73 meters.

What are the bucket specifications of the Palazzani PT 72 wheel loader?

The Palazzani PT 72 wheel loader has a bucket capacity of 1.1 cubic meters, a minimum bucket capacity of 1.1 cubic meters, and a bucket width of 2 meters.
