PL 165 Palazzani PL 165 Specifications & Technical Data (2010—2018)

The Palazzani PL 165 is a wheel loader manufactured by Palazzani from 2010 to 2018. It has a weight of 6.4 tons and a transport le…

The Palazzani PL 165 is a wheel loader manufactured by Palazzani from 2010 to 2018. It has a weight of 6.4 tons and a transport length of 5.6 meters. The bucket capacity is 1.15 cubic meters with a width of 2.1 meters. The maximum discharge height is 4.33 meters and it has a travel speed of 40 km/h. The transport width is 2 meters and the transport height is 2.8 meters. The turning radius outside is 4.45 meters. The minimum bucket capacity is also 1.15 cubic meters.

PL 165

Years of manufacture: 2010—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PL 165 Palazzani

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.4 t

Standard tyres: 16/70-24

Bucket width: 2.1 m

Bucket capacity: 1.15 m³

Bucket capacity min.: 1.15 m³

Steering mode: KL

Transport length: 5.6 m

Transport width: 2 m

Transport height: 2.8 m

Travel speed: 40 km/h

Max. discharge height: 4.33 m

Turning radius outside: 4.45 m

Model series: PL

Engine manuf.: Yanmar

Engine type: 4TNV98T-Z

Engine power: 62.5 kW

Displacement: 3.32 l

Revolutions at max torque: 2500 rpm

More technical details, like: bucket capacity max., lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Palazzani PL 165 FAQ

When was the Palazzani PL 165 manufactured?

The Palazzani PL 165 was manufactured from 2010 to 2018.

How much does the Palazzani PL 165 wheel loader weigh?

The Palazzani PL 165 wheel loader weighs 6.4 tons.

What are the transport dimensions of the Palazzani PL 165 wheel loader?

The Palazzani PL 165 has a transport length of 5.6 meters, a transport width of 2 meters, and a transport height of 2.8 meters.

What is the travel speed of the Palazzani PL 165 wheel loader?

The Palazzani PL 165 has a travel speed of 40 km/h.

What are the undercarriage specifications of the Palazzani PL 165 wheel loader?

The Palazzani PL 165 wheel loader is equipped with standard tyres sized 16/70-24.

What are the maneuverability specifications of the Palazzani PL 165 wheel loader?

The Palazzani PL 165 has an articulated-frame steering system and an outside turning radius of 4.45 meters.

What is the maximum discharge height of the Palazzani PL 165?

The Palazzani PL 165 has a maximum discharge height of 4.33 meters for material handling.

What are the specifications of the primary work tool bucket on the Palazzani PL 165 wheel loader?

The Palazzani PL 165 wheel loader has a bucket with a capacity of 1.15 cubic meters, a minimum bucket capacity of 1.15 cubic meters, and a bucket width of 2.1 meters.
