L 6.5 FT O&K L 6.5 FT Specifications & Technical Data (2003—2005)

The O&K L 6.5 FT Wheel Loader, manufactured from 2003 to 2005, weighs 4.8 tons and has a transport length of 5.15 meters. It has a…

The O&K L 6.5 FT Wheel Loader, manufactured from 2003 to 2005, weighs 4.8 tons and has a transport length of 5.15 meters. It has a bucket capacity of 0.9 cubic meters and a maximum discharge height of 2.545 meters. With a travel speed of 35 km/h, it has a transport width of 1.95 meters and a transport height of 2.77 meters. The wheel loader has a lifting force of 46 kN and a minimum bucket capacity of 0.9 cubic meters.

L 6.5 FT

Years of manufacture: 2003—2005

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - L 6.5 FT O&K

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.8 t

Standard tyres: 365/80R20

Bucket capacity: 0.9 m³

Bucket capacity min.: 0.9 m³

Transport length: 5.15 m

Transport width: 1.95 m

Transport height: 2.77 m

Travel speed: 35 km/h

Max. discharge height: 2.55 m

Lifting force: 46 kN

Model series: L

Engine manuf.: Perkins

Engine type: 704.3

Engine power: 42 kW

Displacement: 3 l

Revolutions at max torque: 2300 rpm

More technical details, like: bucket width, bucket capacity max., steering mode, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

L 6.5 FT O&K Specification for Europe (DE)

O&K L 6.5 FT FAQ

When was the O&K L 6.5 FT manufactured?

The O&K L 6.5 FT was manufactured from 2003 to 2005.

How much does the O&K L 6.5 FT wheel loader weigh?

The O&K L 6.5 FT wheel loader weighs 4.8 tons.

What are the transport dimensions of the O&K L 6.5 FT wheel loader?

The O&K L 6.5 FT has a transport length of 5.15 meters, a transport width of 1.95 meters, and a transport height of 2.77 meters.

What is the travel speed of the O&K L 6.5 FT wheel loader?

The O&K L 6.5 FT wheel loader has a travel speed of 35 km/h.

What are the undercarriage specifications of the O&K L 6.5 FT wheel loader?

The O&K L 6.5 FT wheel loader is equipped with standard tyres sized 365/80R20.

What is the lifting force of the O&K L 6.5 FT wheel loader?

The O&K L 6.5 FT wheel loader has a lifting force of 46 kN.

What is the maximum discharge height of the O&K L 6.5 FT wheel loader?

The O&K L 6.5 FT wheel loader has a maximum discharge height of 2.55 meters.

What is the bucket capacity of the O&K L 6.5 FT wheel loader?

The bucket capacity of the O&K L 6.5 FT wheel loader is 0.9 cubic meters.
