L 5.5 O&K L 5.5 Specifications & Technical Data (2000—2005)

Model rating: 8,00 / 10

The O&K L 5.5 Wheel Loader, manufactured from 2000 to 2005, weighs 4.1 tons and has a transport length of 5.045 meters. It has a b…

The O&K L 5.5 Wheel Loader, manufactured from 2000 to 2005, weighs 4.1 tons and has a transport length of 5.045 meters. It has a bucket capacity of 0.8 cubic meters and a maximum discharge height of 2.37 meters. With a travel speed of 20 km/h, it has a transport width of 1.845 meters and a transport height of 2.665 meters. The machine has a lifting force of 40 kN and a turning radius outside of 3.99 meters. The bucket capacity remains constant at 0.8 cubic meters.

L 5.5

Years of manufacture: 2000—2005

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - L 5.5 O&K

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.1 t

Standard tyres: 335/80R

Bucket capacity: 0.8 m³

Bucket capacity min.: 0.8 m³

Steering mode: KL

Transport length: 5.05 m

Transport width: 1.85 m

Transport height: 2.67 m

Travel speed: 20 km/h

Max. discharge height: 2.37 m

Turning radius outside: 3.99 m

Lifting force: 40 kN

Model series: L

Engine manuf.: Perkins

Engine type: 704.3

Engine power: 39 kW

Displacement: 2.955 l

Revolutions at max torque: 2300 rpm

More technical details, like: bucket width, bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

L 5.5 O&K Specification for Europe (DE)

O&K L 5.5 FAQ

When was the O&K L 5.5 manufactured?

The O&K L 5.5 was manufactured from 2000 to 2005.

How much does the O&K L 5.5 wheel loader weigh?

The O&K L 5.5 wheel loader weighs 4.1 tons.

What are the transport dimensions of the O&K L 5.5 wheel loader?

The O&K L 5.5 wheel loader has a transport length of 5.05 meters, a transport width of 1.85 meters, and a transport height of 2.67 meters.

What is the travel speed of the O&K L 5.5 wheel loader?

The O&K L 5.5 wheel loader has a travel speed of 20 km/h.

What are the undercarriage specifications of the O&K L 5.5 wheel loader?

The O&K L 5.5 wheel loader is equipped with standard tyres sized 335/80R.

What are the maneuverability specifications of the O&K L 5.5 wheel loader?

The O&K L 5.5 wheel loader has an articulated-frame steering mode and an outside turning radius of 3.99 meters.

What is the lifting force of the O&K L 5.5 wheel loader, given that power ratings are not provided?

The O&K L 5.5 wheel loader has a lifting force of 40 kN; no power ratings are provided in the available data.

What is the material handling capacity of the O&K L 5.5 in terms of discharge height?

The O&K L 5.5 has a maximum discharge height of 2.37 meters.

What is the bucket capacity of the O&K L 5.5 wheel loader?

The O&K L 5.5 wheel loader has a bucket capacity of 0.8 cubic meters.
