LW270 B New Holland LW270 B Specifications & Technical Data (2004—2026)

The New Holland LW 270 B is a wheel loader manufactured since 2004. It has a weight of 23 tons and a bucket width of 3 meters. The…

The New Holland LW 270 B is a wheel loader manufactured since 2004. It has a weight of 23 tons and a bucket width of 3 meters. The maximum discharge height is 4 meters, and it can travel at a speed of 39 km/h. The transport width is 2 meters, and the transport height is 3 meters. The turning radius outside is 5 meters. The bucket capacity ranges from 3 to 4 cubic meters. Special equipment includes air conditioning and a diesel particulate filter.

LW270 B

Years of manufacture: 2004—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - LW270 B New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 23.98 t

Standard tyres: 26.5 x 25

Bucket width: 3.15 m

Bucket capacity min.: 3.5 m³

Bucket capacity max.: 4.6 m³

Transport width: 2.96 m

Transport height: 3.587 m

Travel speed: 39.8 km/h

Max. discharge height: 4.814 m

Turning radius outside: 5.785 m

Engine manuf.: Cummins

Engine type: QSM11 668T/M2

Engine power: 239 kW

Displacement: 10.8 l

Revolutions at max torque: 1400 rpm

Max. torque: 1478 Nm

No. of cylinders: 6

Cylinder bore x stroke: 124 x 147 mm

Emission level: Tier 2

More technical details, like: bucket capacity, steering mode, transport length, lifting force, model series, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

LW270 B New Holland Specification for North America (EN)

New Holland LW270 B FAQ

When was the New Holland LW270 B manufactured?

The New Holland LW270 B was first produced in 2004.

How much does the New Holland LW270 B weigh?

The New Holland LW270 B weighs 23.98 tons.

What are the transport dimensions of the New Holland LW270 B wheel loader?

The New Holland LW270 B has a transport width of 2.96 meters and a transport height of 3.59 meters.

What is the travel speed of the New Holland LW270 B wheel loader?

The New Holland LW270 B has a travel speed of 39.8 km/h.

What are the undercarriage specifications of the New Holland LW270 B?

The New Holland LW270 B is equipped with standard tyres sized 26.5 x 25.

What is the turning radius of the New Holland LW270 B wheel loader?

The New Holland LW270 B has an outside turning radius of 5.785 meters.

What is the maximum discharge height of the New Holland LW270 B?

The New Holland LW270 B has a maximum discharge height of 4.81 meters.

What are the bucket specifications of the New Holland LW270 B wheel loader?

The New Holland LW270 B wheel loader has a bucket with a maximum capacity of 4.6 mu00b3, a minimum capacity of 3.5 mu00b3, and a width of 3.15 meters.
