AL 306 Mustang AL 306 Specifications & Technical Data (2008—2020)
Technical specs - AL 306 Mustang
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.52 t
- Standard tyres
- 31x15.50-15 AS
- Bucket width
- 1.2 m
- Bucket capacity
- 0.31 m³
- Bucket capacity min.
- 0.31 m³
- Steering mode
- KL
- Transport length
- 3.975 m
- Transport width
- 1.065 m
- Transport height
- 2.255 m
- Travel speed
- 18.5 km/h
- Max. discharge height
- 2.144 m
- Turning radius outside
- 1.321 m
- Model series
- AL
- Engine manuf.
- Yanmar
- Engine type
- 3TNV88
- Engine power
- 26 kW
- Displacement
- 1.642 l
- Revolutions at max torque
- 2800 rpm
- No. of cylinders
- 3
More technical details, like: bucket capacity max., lifting force, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
No
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
Yes
