L160 Michigan L160 Specifications & Technical Data (1991—2026)

The Michigan L160 is a wheel loader manufactured since 1991. It has a weight of 22 tons and a transport length of 6 meters. The bu…

The Michigan L160 is a wheel loader manufactured since 1991. It has a weight of 22 tons and a transport length of 6 meters. The bucket width is 3 meters, and it has a maximum discharge height of 4 meters. The travel speed of this machine is 39 km/h. The transport width and height are both 3 meters. The bucket capacity ranges from a minimum of 3 cubic meters to a maximum of 6 cubic meters.

Wheel Loaders Michigan L160

Technical specs - L160 Michigan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.3 t
Standard tyres
26.5-25
Bucket width
3.2 m
Bucket capacity min.
3.45 m³
Bucket capacity max.
6.1 m³
Transport length
6.67 m
Transport width
3.004 m
Transport height
3.687 m
Travel speed
39.9 km/h
Max. discharge height
4.157 m
Engine manuf.
Volvo
Engine type
TD102GB
Engine power
194 kW
Displacement
9.6 l
Revolutions at max torque
1400 rpm
Max. torque
962 Nm
No. of cylinders
6
Cylinder bore x stroke
120.65 x 140 mm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Michigan L160 FAQ

When was the Michigan L160 manufactured?

The Michigan L160 was first produced in 1991.

How much does the Michigan L160 wheel loader weigh?

The Michigan L160 wheel loader weighs 22.3 tons.

What are the transport dimensions of the Michigan L160 wheel loader?

The Michigan L160 has a transport length of 6.67 meters, a transport width of 3 meters, and a transport height of 3.69 meters.

What is the travel speed of the Michigan L160 wheel loader?

The Michigan L160 wheel loader has a travel speed of 39.9 km/h.

What is the size of the standard tyres on the Michigan L160 wheel loader?

The Michigan L160 wheel loader is equipped with standard tyres sized 26.5-25.

What is the maximum discharge height of the Michigan L160?

The Michigan L160 has a maximum discharge height of 4.16 meters.

What are the bucket specifications of the Michigan L160 wheel loader?

The Michigan L160 wheel loader has a bucket with a maximum capacity of 6.1 cubic meters, a minimum capacity of 3.45 cubic meters, and a width of 3.2 meters.

How much is a Michigan L160 Wheel loader (1991u20132025) worth?

The residual value of the Michigan L160 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
