Mecalac AT900 Specifications & Technical Data (2021-2024)

Name: Mecalac AT900 Wheel Loaders
Brand: Mecalac

The Mecalac AT900 is a wheel loader manufactured since 2021. It has a weight of 6.55 tons and a transport length of 5.85 meters. T…

The Mecalac AT900 is a wheel loader manufactured since 2021. It has a weight of 6.55 tons and a transport length of 5.85 meters. The bucket capacity ranges from 0.9 to 1.5 cubic meters, with a maximum discharge height of 4.08 meters. It has a travel speed of 30 km/h and a transport width of 2.1 meters. The transport height is 2.91 meters, and the turning radius outside is 4.6 meters. Special equipment includes a quick hitch hydraulic mechanism.

Technical specs - AT900 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.55 t

Standard tyres: 16/70-20

Bucket capacity: 0.9 m³

Bucket capacity min.: 0.9 m³

Bucket capacity max.: 1.5 m³

Steering mode: AL

Transport length: 5.85 m

Transport width: 2.1 m

Transport height: 2.91 m

Travel speed: 30 km/h

Max. discharge height: 4.08 m

Turning radius outside: 4.6 m

Lifting force: 44 kN

Model series: AT

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: bucket width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No
