Mecalac AT1050 Specifications & Technical Data (2021-2024)

Name: Mecalac AT1050 Wheel Loaders
Brand: Mecalac

The Mecalac AT1050 is a wheel loader manufactured since 2021. It has a weight of 7.15 tons and a transport length of 5.92 meters. …

The Mecalac AT1050 is a wheel loader manufactured since 2021. It has a weight of 7.15 tons and a transport length of 5.92 meters. The bucket capacity is 1.05 cubic meters, with a maximum discharge height of 4.05 meters. It has a travel speed of 40 km/h and a transport width of 2.1 meters. The transport height is 2.91 meters. The lifting force is 52 kN, and the turning radius outside is 4.63 meters. The bucket capacity ranges from a minimum of 1.05 cubic meters to a maximum of 1.6 cubic meters.

Technical specs - AT1050 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.15 t

Standard tyres: 16/70-20

Bucket capacity: 1.05 m³

Bucket capacity min.: 1.05 m³

Bucket capacity max.: 1.6 m³

Steering mode: AL

Transport length: 5.92 m

Transport width: 2.1 m

Transport height: 2.91 m

Travel speed: 40 km/h

Max. discharge height: 4.05 m

Turning radius outside: 4.63 m

Lifting force: 52 kN

Model series: AT

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: bucket width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No
