AT1050 Mecalac AT1050 Specifications & Technical Data (2021—2026)

The Mecalac AT1050 is a wheel loader manufactured since 2021. It has a weight of 7.15 tons and a transport length of 5.92 meters. …

The Mecalac AT1050 is a wheel loader manufactured since 2021. It has a weight of 7.15 tons and a transport length of 5.92 meters. The bucket capacity is 1.05 cubic meters, with a maximum discharge height of 4.05 meters. The travel speed is 30 km/h, and the transport width is 2.1 meters. The transport height is 2.91 meters. It has a lifting force of 52 kN and a turning radius outside of 4.63 meters. The bucket capacity ranges from a minimum of 1.05 cubic meters to a maximum of 1.6 cubic meters.

AT1050

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AT1050 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.15 t

Standard tyres: 16/70-20

Bucket capacity: 1.05 m³

Bucket capacity min.: 1.05 m³

Bucket capacity max.: 1.6 m³

Steering mode: AL

Transport length: 5.92 m

Transport width: 2.1 m

Transport height: 2.91 m

Travel speed: 30 km/h

Max. discharge height: 4.05 m

Turning radius outside: 4.63 m

Lifting force: 52 kN

Model series: AT

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Cylinder bore x stroke: 92x110 mm

Emission level: EU V

More technical details, like: bucket width, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AT1050 FAQ

When was the Mecalac AT1050 manufactured?

The Mecalac AT1050 was first produced in 2021.

How much does the Mecalac AT1050 wheel loader weigh?

The Mecalac AT1050 wheel loader weighs 7.15 tons.

What are the transport dimensions of the Mecalac AT1050 wheel loader?

The Mecalac AT1050 has a transport length of 5.92 meters, a transport width of 2.1 meters, and a transport height of 2.91 meters.

What is the travel speed of the Mecalac AT1050 wheel loader?

The Mecalac AT1050 has a travel speed of 30 km/h.

What is the size of the standard tyres on the Mecalac AT1050 wheel loader?

The Mecalac AT1050 wheel loader is equipped with standard tyres sized 16/70-20.

What are the maneuverability specifications of the Mecalac AT1050 wheel loader?

The Mecalac AT1050 has an outside turning radius of 4.63 meters and features all-wheel steering.

What is the power rating of the Mecalac AT1050?

There is no power rating data available for the Mecalac AT1050 in the provided source.

What is the material handling capacity of the Mecalac AT1050 in terms of discharge height?

The Mecalac AT1050 has a maximum discharge height of 4.05 meters.

What are the bucket capacity specifications of the Mecalac AT1050 wheel loader?

The Mecalac AT1050 wheel loader has a bucket capacity ranging from a minimum of 1.05 mu00b3 to a maximum of 1.6 mu00b3, with a standard bucket capacity of 1.05 mu00b3.
