AS900tele Mecalac AS900tele Specifications & Technical Data (2015—2020)

The Mecalac AS900tele is a wheel loader manufactured from 2015 to 2020. It has a weight of 7.25 tons and a transport length of 6.2…

The Mecalac AS900tele is a wheel loader manufactured from 2015 to 2020. It has a weight of 7.25 tons and a transport length of 6.27 meters. The bucket capacity ranges from 0.7 to 1.2 cubic meters, with a maximum discharge height of 4.1 meters. It has a travel speed of 20 km/h and a transport width of 2.1 meters. The transport height is 2.91 meters. The machine is equipped with special features such as a quick hitch hydr., swing loader, and telescopic capabilities. It also has a lifting force of 37 kN.

AS900tele

Years of manufacture: 2015—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AS900tele Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.25 t

Standard tyres: 16/70-20

Bucket capacity: 0.7 m³

Bucket capacity min.: 0.7 m³

Bucket capacity max.: 1.2 m³

Steering mode: AL

Transport length: 6.27 m

Transport width: 2.1 m

Transport height: 2.91 m

Travel speed: 20 km/h

Max. discharge height: 4.1 m

Lifting force: 37 kN

Model series: AS

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Revolutions at max torque: 2600 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Emission level: Tier 4 f

More technical details, like: bucket width, turning radius outside, dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: Yes
telescopic: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AS900tele FAQ

When was the Mecalac AS900tele manufactured?

The Mecalac AS900tele was manufactured from 2015 to 2020.

How much does the Mecalac AS900tele wheel loader weigh?

The Mecalac AS900tele wheel loader weighs 7.25 tons.

What are the transport dimensions of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele has a transport length of 6.27 meters, a transport width of 2.1 meters, and a transport height of 2.91 meters.

What is the travel speed of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele has a travel speed of 20 km/h.

What is the standard tyre size of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele wheel loader has standard tyres sized 16/70-20.

What is the steering mode of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele wheel loader has all-wheel steering.

What is the power rating of the Mecalac AS900tele wheel loader?

The source data does not provide power rating information for the Mecalac AS900tele wheel loader.

What is the material handling capacity of the Mecalac AS900tele in terms of maximum discharge height?

The Mecalac AS900tele has a maximum discharge height of 4.1 meters.

What are the bucket capacity specifications of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele wheel loader has a bucket capacity ranging from 0.7 cubic meters to a maximum of 1.2 cubic meters.
