AS900 Mecalac AS900 Specifications & Technical Data (2021—2022)

The Mecalac AS900 is a wheel loader manufactured by Mecalac from 2021 to 2022. It has a weight of 6.64 tons and a transport length…

The Mecalac AS900 is a wheel loader manufactured by Mecalac from 2021 to 2022. It has a weight of 6.64 tons and a transport length of 5.59 meters. The bucket capacity is 0.9 cubic meters, with a maximum discharge height of 2.65 meters. The travel speed of the AS900 is 20 km/h, and it has a transport width of 2.1 meters and a transport height of 2.83 meters. The lifting force of this wheel loader is 75 kN. It has a maximum bucket capacity of 1.5 cubic meters and a minimum bucket capacity of 0.9 cubic meters. The AS900 is equipped with special features such as air conditioning, a diesel particulate filter, a quick hitch hydraulic system, and a swing loader.

AS900

Years of manufacture: 2021—2022

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AS900 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.64 t

Standard tyres: 14.5-20

Bucket capacity: 0.9 m³

Bucket capacity min.: 0.9 m³

Bucket capacity max.: 1.5 m³

Steering mode: AL

Transport length: 5.59 m

Transport width: 2.1 m

Transport height: 2.83 m

Travel speed: 20 km/h

Max. discharge height: 2.65 m

Lifting force: 75 kN

Model series: AS

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Cylinder bore x stroke: 92x110 mm

Emission level: EU V

More technical details, like: bucket width, turning radius outside, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: Yes
telescopic: No
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AS900 FAQ

When was the Mecalac AS900 manufactured?

The Mecalac AS900 was manufactured from 2021 to 2022.

How much does the Mecalac AS900 wheel loader weigh?

The Mecalac AS900 wheel loader weighs 6.64 tons.

What are the transport dimensions of the Mecalac AS900 wheel loader?

The Mecalac AS900 has a transport length of 5.59 meters, a transport width of 2.1 meters, and a transport height of 2.83 meters.

What is the travel speed of the Mecalac AS900 wheel loader?

The Mecalac AS900 wheel loader has a travel speed of 20 km/h.

What are the undercarriage specifications of the Mecalac AS900 wheel loader?

The Mecalac AS900 wheel loader is equipped with standard tyres sized 14.5-20.

What is the steering mode of the Mecalac AS900 wheel loader?

The Mecalac AS900 wheel loader features all-wheel steering.

What is the power rating of the Mecalac AS900 wheel loader?

The source data does not provide power rating information for the Mecalac AS900 wheel loader.

What is the maximum discharge height of the Mecalac AS900 wheel loader?

The Mecalac AS900 wheel loader has a maximum discharge height of 2.65 meters.

What are the bucket capacity specifications of the Mecalac AS900 wheel loader?

The Mecalac AS900 wheel loader has a bucket capacity ranging from 0.9 mu00b3 to a maximum of 1.5 mu00b3, with a standard bucket capacity of 0.9 mu00b3.
