AS210e Mecalac AS210e Specifications & Technical Data (2015—2019)

The Mecalac AS210e is a wheel loader manufactured by Mecalac from 2015 to 2019. It has a weight of 15 tons and a transport length …

The Mecalac AS210e is a wheel loader manufactured by Mecalac from 2015 to 2019. It has a weight of 15 tons and a transport length of 7.155 meters. The bucket capacity is 2.1 cubic meters, with a maximum discharge height of 3.42 meters. The travel speed of the machine is 35 km/h. It has a transport width of 2.7 meters and a transport height of 3.155 meters. The lifting force of the loader is 106 kN. The bucket capacity ranges from a minimum of 2.1 cubic meters to a maximum of 3 cubic meters. The special equipment includes air conditioning, a diesel particulate filter, a quick hitch hydraulic system, and a swing loader.

AS210e

Years of manufacture: 2015—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AS210e Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 15 t

Standard tyres: 20.5-25

Bucket capacity: 2.1 m³

Bucket capacity min.: 2.1 m³

Bucket capacity max.: 3 m³

Steering mode: AL

Transport length: 7.155 m

Transport width: 2.7 m

Transport height: 3.155 m

Travel speed: 35 km/h

Max. discharge height: 3.42 m

Lifting force: 106 kN

Model series: AS

Engine manuf.: Deutz

Engine type: TCD6.1 L6

Engine power: 129 kW

More technical details, like: bucket width, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: Yes
telescopic: No
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AS210e FAQ

When was the Mecalac AS210e manufactured?

The Mecalac AS210e was manufactured from 2015 to 2019.

How much does the Mecalac AS210e wheel loader weigh?

The Mecalac AS210e wheel loader weighs 15 tons.

What are the transport dimensions of the Mecalac AS210e wheel loader?

The Mecalac AS210e has a transport length of 7.16 meters, a transport width of 2.7 meters, and a transport height of 3.16 meters.

What is the travel speed of the Mecalac AS210e wheel loader?

The Mecalac AS210e has a travel speed of 35 km/h.

What are the undercarriage specifications of the Mecalac AS210e wheel loader?

The Mecalac AS210e wheel loader is equipped with standard tyres sized 20.5-25.

What is the steering mode of the Mecalac AS210e?

The Mecalac AS210e has an all-wheel steering mode.

What are the power ratings of the Mecalac AS210e wheel loader?

There is no power rating information available for the Mecalac AS210e wheel loader in the provided data.

What is the maximum discharge height of the Mecalac AS210e wheel loader?

The Mecalac AS210e wheel loader has a maximum discharge height of 3.42 meters.

What are the bucket capacity specifications of the Mecalac AS210e wheel loader?

The Mecalac AS210e has a bucket capacity of 2.1 mu00b3, with a minimum capacity of 2.1 mu00b3 and a maximum capacity of 3 mu00b3.
