AS 900 Mecalac AS 900 Specifications & Technical Data (2012—2015)

The Mecalac AS 900 is a wheel loader manufactured by Mecalac from 2012 to 2015. It has a weight of 6.6 tons and a transport length…

The Mecalac AS 900 is a wheel loader manufactured by Mecalac from 2012 to 2015. It has a weight of 6.6 tons and a transport length of 5.59 meters. The bucket capacity ranges from 0.9 to 1.5 cubic meters. The maximum discharge height is 3.13 meters. It has a travel speed of 40 km/h and a transport width of 2.1 meters. The transport height is 2.83 meters. It is equipped with special features such as a quick hitch hydr. and a swing loader.

Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900
Wheel Loaders Mecalac AS 900

Technical specs - AS 900 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.6 t
Standard tyres
14.5-20
Bucket capacity
0.9 m³
Bucket capacity min.
0.9 m³
Bucket capacity max.
1.5 m³
Steering mode
AL
Transport length
5.59 m
Transport width
2.1 m
Transport height
2.83 m
Travel speed
40 km/h
Max. discharge height
3.13 m
Model series
AS
Engine manuf.
Cummins
Engine type
B3.3ST
Engine power
55 kW
Displacement
3.3 l
Revolutions at max torque
1600 rpm

More technical details, like: bucket width, turning radius outside, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
Yes
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Mecalac AS 900 FAQ

When was the Mecalac AS 900 manufactured?

The Mecalac AS 900 was manufactured from 2012 to 2015.

How much does the Mecalac AS 900 weigh?

The Mecalac AS 900 weighs 6.6 tons.

What are the transport dimensions of the Mecalac AS 900 wheel loader?

The Mecalac AS 900 has a transport length of 5.59 meters, a transport width of 2.1 meters, and a transport height of 2.83 meters.

What is the travel speed of the Mecalac AS 900 wheel loader?

The Mecalac AS 900 has a travel speed of 40 km/h.

What are the standard tyre specifications of the Mecalac AS 900?

The Mecalac AS 900 has standard tyres sized 14.5-20.

What is the steering mode of the Mecalac AS 900?

The Mecalac AS 900 has an all-wheel steering mode.

What is the maximum discharge height of the Mecalac AS 900?

The Mecalac AS 900 has a maximum discharge height of 3.13 meters.

What are the bucket capacity specifications of the Mecalac AS 900 wheel loader?

The Mecalac AS 900 wheel loader has a bucket capacity ranging from 0.9 mu00b3 to a maximum of 1.5 mu00b3, with a standard bucket capacity of 0.9 mu00b3.

How much is a Mecalac AS 900 Wheel loader (2012u20132015) worth?

The residual value of the Mecalac AS 900 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
