AS 700 Mecalac AS 700 Specifications & Technical Data (2012—2015)

The Mecalac AS 700 is a wheel loader manufactured by Mecalac from 2012 to 2015. It has a weight of 6 tons and a transport length o…

The Mecalac AS 700 is a wheel loader manufactured by Mecalac from 2012 to 2015. It has a weight of 6 tons and a transport length of 5.55 meters. The bucket capacity is 0.7 cubic meters, and it has a maximum discharge height of 3.12 meters. The travel speed of this machine is 40 km/h. It has a transport width of 1.95 meters and a transport height of 2.68 meters. The bucket capacity minimum is also 0.7 cubic meters. Additionally, it is equipped with a quick hitch hydr.

AS 700

Years of manufacture: 2012—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AS 700 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6 t

Standard tyres: 14.5-20

Bucket capacity: 0.7 m³

Bucket capacity min.: 0.7 m³

Steering mode: AL

Transport length: 5.55 m

Transport width: 1.95 m

Transport height: 2.68 m

Travel speed: 40 km/h

Max. discharge height: 3.12 m

Model series: AS

Engine manuf.: Cummins

Engine type: B3.3

Engine power: 48 kW

Displacement: 3.3 l

Revolutions at max torque: 1600 rpm

More technical details, like: bucket width, bucket capacity max., turning radius outside, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AS 700 FAQ

When was the Mecalac AS 700 manufactured?

The Mecalac AS 700 was manufactured from 2012 to 2015.

How much does the Mecalac AS 700 wheel loader weigh?

The Mecalac AS 700 wheel loader weighs 6 tons.

What are the transport dimensions of the Mecalac AS 700 wheel loader?

The Mecalac AS 700 has a transport length of 5.55 meters, a transport width of 1.95 meters, and a transport height of 2.68 meters.

What is the travel speed of the Mecalac AS 700 wheel loader?

The Mecalac AS 700 has a travel speed of 40 km/h.

What are the undercarriage specifications of the Mecalac AS 700 wheel loader?

The Mecalac AS 700 wheel loader is equipped with standard tyres sized 14.5-20.

What is the steering mode of the Mecalac AS 700?

The Mecalac AS 700 has an all-wheel steering mode.

What is the maximum discharge height of the Mecalac AS 700?

The Mecalac AS 700 has a maximum discharge height of 3.12 meters.

What is the bucket capacity of the Mecalac AS 700 wheel loader?

The bucket capacity of the Mecalac AS 700 wheel loader is 0.7 cubic meters.

How much is a Mecalac AS 700 Wheel loader (2012u20132015) worth?

The residual value of the Mecalac AS 700 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Machine inspection

Ask for inspection of your Mecalac AS 700 from experts

Mevas is an international operating inspection service for used heavy machinery. Construction machinery inspectors are available in more than 20 countries.

Use this service to minimise the risk when buying used equipment. An inspection by Mevas costs less than repairing a defective hydraulic cylinder.

Enquire machine inspection

Provided by:

Buy & Rent

Compare Mecalac AS 700 with similar Wheel Loaders

Mecalac AS 700

Weight:: 6 t

Standard tyres:: 14.5-20

Bucket capacity:: 0.7 m³

Bucket capacity min.:: 0.7 m³

Redrock TH 280

Weight:: 6.45 t

Standard tyres:: 17.5x24

Bucket capacity:: 1.1 m³

Bucket capacity min.:: 1.1 m³

Benfra 215 B

Weight:: 6.7 t

Standard tyres:: 14.9-24

Bucket capacity:: 1 m³

Bucket capacity min.:: 1 m³

Weimar WL 470

Weight:: 5 t

Standard tyres:: 405/70 R 20

Bucket capacity:: 0.8 m³

Bucket capacity min.:: 0.8 m³

Mecalac AS 900 tele

Weight:: 7.2 t

Standard tyres:: 16/17-20

Bucket capacity:: 0.9 m³

Bucket capacity min.:: 0.9 m³
