AS 210 e Mecalac AS 210 e Specifications & Technical Data (2012—2014)

The Mecalac AS 210 e is a wheel loader manufactured by Mecalac from 2012 to 2014. It has a weight of 14.5 tons and a transport len…

The Mecalac AS 210 e is a wheel loader manufactured by Mecalac from 2012 to 2014. It has a weight of 14.5 tons and a transport length of 7.155 meters. The bucket capacity is 2.1 cubic meters, and it has a maximum discharge height of 3.42 meters. The travel speed of this wheel loader is 35 km/h. It has a transport width of 2.605 meters and a transport height of 3.155 meters. The lifting force of the AS 210 e is 106 kN. It is equipped with special features such as a quick hitch hydr. and a swing loader.

Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e
Wheel Loaders Mecalac AS 210 e

Technical specs - AS 210 e Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
14.5 t
Standard tyres
20.5-25
Bucket capacity
2.1 m³
Bucket capacity min.
2.1 m³
Steering mode
AL
Transport length
7.155 m
Transport width
2.605 m
Transport height
3.155 m
Travel speed
35 km/h
Max. discharge height
3.42 m
Lifting force
106 kN
Model series
AS

More technical details, like: bucket width, bucket capacity max., turning radius outside, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
Yes
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Mecalac AS 210 e FAQ

When was the Mecalac AS 210 e manufactured?

The Mecalac AS 210 e was manufactured from 2012 to 2014.

How much does the Mecalac AS 210 e weigh?

The Mecalac AS 210 e weighs 14.5 tons.

What are the transport dimensions of the Mecalac AS 210 e wheel loader?

The Mecalac AS 210 e has a transport length of 7.16 meters, a transport width of 2.61 meters, and a transport height of 3.16 meters.

What is the travel speed of the Mecalac AS 210 e wheel loader?

The Mecalac AS 210 e has a travel speed of 35 km/h.

What is the standard tyre size of the Mecalac AS 210 e wheel loader?

The Mecalac AS 210 e wheel loader is equipped with standard tyres sized 20.5-25.

What is the steering mode of the Mecalac AS 210 e?

The Mecalac AS 210 e has an all-wheel steering mode.

What is the lifting force of the Mecalac AS 210 e wheel loader?

The Mecalac AS 210 e wheel loader has a lifting force of 106 kN.

What is the material handling capacity of the Mecalac AS 210 e in terms of discharge height?

The Mecalac AS 210 e has a maximum discharge height of 3.42 meters.

What is the bucket capacity of the Mecalac AS 210 e wheel loader?

The bucket capacity of the Mecalac AS 210 e wheel loader is 2.1 cubic meters.
