AF 1050 Mecalac AF 1050 Specifications & Technical Data (2012—2015)

The Mecalac AF 1050 is a wheel loader manufactured from 2012 to 2015. It has a weight of 5.8 tons and a transport length of 6.03 m…

The Mecalac AF 1050 is a wheel loader manufactured from 2012 to 2015. It has a weight of 5.8 tons and a transport length of 6.03 meters. The bucket capacity ranges from 1.05 to 1.7 cubic meters, with a maximum discharge height of 2.85 meters. It has a travel speed of 20 km/h and a transport width of 2.1 meters. The transport height is 2.83 meters, and it has a lifting force of 65 kN. Special equipment includes a quick hitch hydraulic mechanism.

AF 1050

Years of manufacture: 2012—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AF 1050 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.8 t

Standard tyres: 14.5-20

Bucket capacity: 1.05 m³

Bucket capacity min.: 1.05 m³

Bucket capacity max.: 1.7 m³

Steering mode: AL

Transport length: 6.03 m

Transport width: 2.1 m

Transport height: 2.83 m

Travel speed: 20 km/h

Max. discharge height: 2.85 m

Lifting force: 65 kN

Model series: AF

Engine manuf.: Cummins

Engine type: B3.3

Engine power: 48 kW

Displacement: 3.3 l

Revolutions at max torque: 1600 rpm

More technical details, like: bucket width, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AF 1050 FAQ

When was the Mecalac AF 1050 manufactured?

The Mecalac AF 1050 was manufactured from 2012 to 2015.

How much does the Mecalac AF 1050 weigh?

The Mecalac AF 1050 weighs 5.8 tons.

What are the transport dimensions of the Mecalac AF 1050 wheel loader?

The Mecalac AF 1050 has a transport length of 6.03 meters, a transport width of 2.1 meters, and a transport height of 2.83 meters.

What is the travel speed of the Mecalac AF 1050 wheel loader?

The Mecalac AF 1050 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Mecalac AF 1050 wheel loader?

The Mecalac AF 1050 is equipped with standard tyres sized 14.5-20.

What is the steering mode of the Mecalac AF 1050?

The Mecalac AF 1050 has an all-wheel steering mode.

What is the power rating of the Mecalac AF 1050 wheel loader?

The source data does not provide power rating information for the Mecalac AF 1050 wheel loader.

What is the material handling capacity of the Mecalac AF 1050 in terms of discharge height?

The Mecalac AF 1050 has a maximum discharge height of 2.85 meters.

What are the bucket capacity specifications of the Mecalac AF 1050 wheel loader?

The Mecalac AF 1050 wheel loader has a bucket capacity ranging from 1.05 mu00b3 to a maximum of 1.7 mu00b3, with a minimum capacity of 1.05 mu00b3.
