MLA 3-35 H Manitou MLA 3-35 H Specifications & Technical Data (2021—2026)

The Manitou MLA 3-35 H is a wheel loader manufactured since 2021. It has a weight of 2.649 tons and a transport length of 3.35 met…

The Manitou MLA 3-35 H is a wheel loader manufactured since 2021. It has a weight of 2.649 tons and a transport length of 3.35 meters. The maximum discharge height is 2.86 meters, and it can travel at a speed of 19 km/h. The transport width is 1.32 meters, and the transport height is 2.26 meters. It has a lifting force of 254 kN and a turning radius outside of 2.63 meters.

Wheel Loaders Manitou MLA 3-35 H

Visit Manitou live at

Technical specs - MLA 3-35 H Manitou

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.649 t
Standard tyres
31x15.5 15 SK 02
Steering mode
KL
Transport length
3.35 m
Transport width
1.32 m
Transport height
2.26 m
Travel speed
19 km/h
Max. discharge height
2.86 m
Turning radius outside
2.63 m
Lifting force
254 kN
Engine manuf.
Yanmar
Engine type
3TNV88
Engine power
26 kW
Displacement
1.6 l
Max. torque
102.7/1680 Nm
No. of cylinders
3
Emission level
3A

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., model series, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Manitou MLA 3-35 H FAQ

When was the Manitou MLA 3-35 H manufactured?

The Manitou MLA 3-35 H was first produced in 2021.

How much does the Manitou MLA 3-35 H wheel loader weigh?

The Manitou MLA 3-35 H wheel loader weighs 2.65 tons.

What are the transport dimensions of the Manitou MLA 3-35 H wheel loader?

The Manitou MLA 3-35 H has a transport length of 3.35 meters, a transport width of 1.32 meters, and a transport height of 2.26 meters.

What is the travel speed of the Manitou MLA 3-35 H wheel loader?

The Manitou MLA 3-35 H has a travel speed of 19 km/h.

What are the undercarriage specifications of the Manitou MLA 3-35 H?

The Manitou MLA 3-35 H is equipped with standard tyres sized 31x15.5 15 SK 02.

What are the maneuverability specifications of the Manitou MLA 3-35 H wheel loader?

The Manitou MLA 3-35 H has an articulated-frame steering system and an outside turning radius of 2.63 meters.

What are the power ratings of the Manitou MLA 3-35 H?

The available data does not provide power ratings for the Manitou MLA 3-35 H.

What is the maximum discharge height of the Manitou MLA 3-35 H wheel loader?

The Manitou MLA 3-35 H has a maximum discharge height of 2.86 meters.

How much is a Manitou MLA 3-35 H Wheel loader (2021u20132025) worth?

The residual value of the Manitou MLA 3-35 H depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
