L 15 Ljungby L 15 Specifications & Technical Data (2010—2018)

The Ljungby L 15 Wheel Loader, manufactured from 2010 to 2018, is a construction machine with a weight of 16 tons. It has a transp…

The Ljungby L 15 Wheel Loader, manufactured from 2010 to 2018, is a construction machine with a weight of 16 tons. It has a transport length of 7.3 meters and a bucket capacity of 2.8 cubic meters. The bucket width is 2.8 meters, and the maximum discharge height is 4.18 meters. The transport width is 2.535 meters, and the transport height is 3.31 meters. With a lifting force of 120 kN, it offers strong capabilities. The turning radius outside is 5.95 meters, providing maneuverability. The bucket capacity minimum remains at 2.8 cubic meters.

L 15

Years of manufacture: 2010—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - L 15 Ljungby

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 16 t

Standard tyres: 20.5 R25

Bucket width: 2.8 m

Bucket capacity: 2.8 m³

Bucket capacity min.: 2.8 m³

Steering mode: KL

Transport length: 7.3 m

Transport width: 2.535 m

Transport height: 3.31 m

Max. discharge height: 4.18 m

Turning radius outside: 5.95 m

Lifting force: 120 kN

Engine manuf.: Mercedes-Benz

Engine type: OM904 LAT

Engine power: 130 kW

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Ljungby L 15 FAQ

When was the Ljungby L 15 manufactured?

The Ljungby L 15 was manufactured from 2010 to 2018.

How much does the Ljungby L 15 wheel loader weigh?

The Ljungby L 15 wheel loader weighs 16 tons.

What are the transport dimensions of the Ljungby L 15 wheel loader?

The Ljungby L 15 has a transport length of 7.3 meters, a transport width of 2.54 meters, and a transport height of 3.31 meters.

What are the undercarriage specifications of the Ljungby L 15 wheel loader?

The Ljungby L 15 wheel loader is equipped with standard tyres sized 20.5 R25.

What are the maneuverability specifications of the Ljungby L 15 wheel loader?

The Ljungby L 15 wheel loader has an articulated-frame steering system and an outside turning radius of 5.95 meters.

What is the lifting force of the Ljungby L 15 wheel loader?

The Ljungby L 15 wheel loader has a lifting force of 120 kN.

What is the maximum discharge height of the Ljungby L 15?

The Ljungby L 15 has a maximum discharge height of 4.18 meters.

What are the specifications of the primary work tool on the Ljungby L 15 wheel loader?

The Ljungby L 15 wheel loader is equipped with a bucket that has a capacity of 2.8 cubic meters and a width of 2.8 meters.
