L 538 Speeder Liebherr L 538 Speeder Specifications & Technical Data (2022—2026)

The Liebherr L 538 Speeder is a wheel loader manufactured by Liebherr since 2022. It has a weight of 14.85 tons and a transport le…

The Liebherr L 538 Speeder is a wheel loader manufactured by Liebherr since 2022. It has a weight of 14.85 tons and a transport length of 7.63 meters. The bucket capacity is 2.6 cubic meters, with a bucket width of 2.72 meters. The maximum discharge height is 2.96 meters, and it has a travel speed of 40 km/h. The transport width and height are both 2.72 meters and 3.25 meters respectively. The turning radius outside is 6.14 meters. The machine is equipped with a diesel particulate filter. The bucket capacity ranges from a minimum of 2.2 cubic meters to a maximum of 6.5 cubic meters.

Wheel Loaders Liebherr L 538 Speeder

Visit Liebherr live at

Technical specs - L 538 Speeder Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
14.85 t
Standard tyres
20.5 R25
Bucket width
2.72 m
Bucket capacity
2.6 m³
Bucket capacity min.
2.2 m³
Bucket capacity max.
6.5 m³
Steering mode
KL
Transport length
7.63 m
Transport width
2.72 m
Transport height
3.25 m
Travel speed
40 km/h
Max. discharge height
2.96 m
Turning radius outside
6.14 m
Model series
L
Engine manuf.
John Deere
Engine type
6068HB551
Engine power
168 kW
Displacement
6.8 l
Revolutions at max torque
2200 rpm
Max. torque
970/1600 Nm
No. of cylinders
6
Cylinder bore x stroke
106x127 mm
Emission level
V

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr L 538 Speeder FAQ

When was the Liebherr L 538 Speeder manufactured?

The Liebherr L 538 Speeder was first produced in 2022.

How much does the Liebherr L 538 Speeder weigh?

The Liebherr L 538 Speeder weighs 14.85 tons.

What are the transport dimensions of the Liebherr L 538 Speeder wheel loader?

The Liebherr L 538 Speeder has a transport length of 7.63 meters, a transport width of 2.72 meters, and a transport height of 3.25 meters.

What is the travel speed of the Liebherr L 538 Speeder wheel loader?

The Liebherr L 538 Speeder has a travel speed of 40 km/h.

What is the average fuel consumption of the Liebherr L 538 Speeder wheel loader?

The Liebherr L 538 Speeder has an average fuel consumption of 10.52 liters per hour.

What are the undercarriage specifications of the Liebherr L 538 Speeder?

The Liebherr L 538 Speeder is equipped with standard tyres sized 20.5 R25.

What are the maneuverability specifications of the Liebherr L 538 Speeder wheel loader?

The Liebherr L 538 Speeder has an articulated-frame steering mode and an outside turning radius of 6.14 meters.

What is the maximum discharge height of the Liebherr L 538 Speeder?

The Liebherr L 538 Speeder has a maximum discharge height of 2.96 meters.

What are the specifications of the bucket on the Liebherr L 538 Speeder wheel loader?

The Liebherr L 538 Speeder features a bucket with a capacity ranging from 2.2 to 6.5 cubic meters, a standard capacity of 2.6 cubic meters, and a width of 2.72 meters.

How much is a Liebherr L 538 Speeder Wheel loader (2022u20132025) worth?

The residual value of the Liebherr L 538 Speeder depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
