L 534 Liebherr L 534 Specifications & Technical Data (2002—2026)

The Liebherr L 534 is a wheel loader manufactured since 2002. It has a weight of 12.1 tons and a transport length of 7.7 meters. T…

The Liebherr L 534 is a wheel loader manufactured since 2002. It has a weight of 12.1 tons and a transport length of 7.7 meters. The bucket capacity is 2.8 cubic meters with a width of 2.5 meters. The maximum discharge height is 5.34 meters. It has a travel speed of 34 km/h and a transport width of 2.5 meters. The transport height is 3.25 meters. The lifting force is 135 kN and it has a turning radius outside of 5.925 meters.

Wheel Loaders Liebherr L 534

Visit Liebherr live at

Technical specs - L 534 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
12.1 t
Standard tyres
20.5 R25
Bucket width
2.5 m
Bucket capacity
2.8 m³
Steering mode
KL
Transport length
7.7 m
Transport width
2.5 m
Transport height
3.25 m
Travel speed
34 km/h
Max. discharge height
5.34 m
Turning radius outside
5.925 m
Lifting force
135 kN
Model series
L
Engine manuf.
Liebherr
Engine type
D 504 TI
Engine power
100 kW
Displacement
4.5 l
Revolutions at max torque
2400 rpm
Max. torque
498 Nm
No. of cylinders
4
Cylinder bore x stroke
106x127 mm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr L 534 FAQ

When was the Liebherr L 534 manufactured?

The Liebherr L 534 was first produced in 2002.

How much does the Liebherr L 534 wheel loader weigh?

The Liebherr L 534 wheel loader weighs 12.1 tons.

What are the transport dimensions of the Liebherr L 534 wheel loader?

The Liebherr L 534 has a transport length of 7.7 meters, a transport width of 2.5 meters, and a transport height of 3.25 meters.

What is the travel speed of the Liebherr L 534 wheel loader?

The Liebherr L 534 wheel loader has a travel speed of 34 km/h.

What are the undercarriage specifications of the Liebherr L 534 wheel loader?

The Liebherr L 534 wheel loader is equipped with standard tyres sized 20.5 R25.

What are the maneuverability specifications of the Liebherr L 534 wheel loader?

The Liebherr L 534 has an outside turning radius of 5.925 meters and uses articulated-frame steering for maneuverability.

What is the lifting force of the Liebherr L 534 wheel loader?

The Liebherr L 534 wheel loader has a lifting force of 135 kN.

What is the maximum discharge height of the Liebherr L 534?

The Liebherr L 534 has a maximum discharge height of 5.34 meters.

What are the specifications of the primary work tool on the Liebherr L 534 wheel loader?

The primary work tool of the Liebherr L 534 wheel loader has a bucket capacity of 2.8 cubic meters and a bucket width of 2.5 meters.

How much is a Liebherr L 534 Wheel loader (2002u20132025) worth?

The residual value of the Liebherr L 534 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
