L 524 Liebherr L 524 Specifications & Technical Data (2019—2026)

The Liebherr L 524 is a wheel loader manufactured since 2019. It has a weight of 10.4 tons and a transport length of 6.82 meters. …

The Liebherr L 524 is a wheel loader manufactured since 2019. It has a weight of 10.4 tons and a transport length of 6.82 meters. The bucket capacity is 4 cubic meters with a width of 2.5 meters. The maximum discharge height is 2.87 meters. It has a travel speed of 40 km/h and a transport width of 2.46 meters. The transport height is 3.2 meters and the turning radius outside is 5.17 meters. The bucket capacity minimum is also 4 cubic meters. Additionally, it is equipped with a diesel particulate filter.

Wheel Loaders Liebherr L 524
Wheel Loaders Liebherr L 524
Wheel Loaders Liebherr L 524
Wheel Loaders Liebherr L 524

Visit Liebherr live at

Technical specs - L 524 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
10.4 t
Standard tyres
17.5R25
Bucket width
2.5 m
Bucket capacity
4 m³
Bucket capacity min.
4 m³
Steering mode
KL
Transport length
6.82 m
Transport width
2.46 m
Transport height
3.2 m
Travel speed
40 km/h
Max. discharge height
2.87 m
Turning radius outside
5.17 m
Model series
L
Engine manuf.
John Deere
Engine type
4045HF286
Engine power
86 kW
Displacement
4.5 l
Revolutions at max torque
1500 rpm
Emission level
IIIA

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr L 524 FAQ

When was the Liebherr L 524 manufactured?

The Liebherr L 524 was first produced in 2019.

How much does the Liebherr L 524 wheel loader weigh?

The Liebherr L 524 wheel loader weighs 10.4 tons.

What are the transport dimensions of the Liebherr L 524 wheel loader?

The Liebherr L 524 wheel loader has a transport length of 6.82 meters, a transport width of 2.46 meters, and a transport height of 3.2 meters.

What is the travel speed of the Liebherr L 524 wheel loader?

The Liebherr L 524 has a travel speed of 40 km/h.

What is the standard tyre size of the Liebherr L 524 wheel loader?

The Liebherr L 524 wheel loader has standard tyres sized 17.5R25.

What are the maneuverability specifications of the Liebherr L 524 wheel loader?

The Liebherr L 524 wheel loader has an articulated-frame steering system and an outside turning radius of 5.17 meters.

What is the maximum discharge height of the Liebherr L 524?

The Liebherr L 524 has a maximum discharge height of 2.87 meters.

What are the specifications of the bucket on the Liebherr L 524 wheel loader?

The Liebherr L 524 wheel loader has a bucket with a capacity of 4 cubic meters, a minimum bucket capacity of 4 cubic meters, and a width of 2.5 meters.

How much is a Liebherr L 524 Wheel loader (2019u20132025) worth?

The residual value of the Liebherr L 524 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
