L 524 Liebherr L 524 Specifications & Technical Data (2013—2016)

Model rating
5,00 / 10

The Liebherr L 524 is a wheel loader manufactured from 2013 to 2016. It has a weight of 10.4 tons and a transport length of 6.82 m…

The Liebherr L 524 is a wheel loader manufactured from 2013 to 2016. It has a weight of 10.4 tons and a transport length of 6.82 meters. The bucket capacity is 2.1 cubic meters, with a width of 2.5 meters. The maximum discharge height is 2.85 meters. It has a travel speed of 40 km/h and a transport width of 2.5 meters. The transport height is 3.2 meters and the turning radius outside is 5.7 meters. The minimum bucket capacity is also 2.1 cubic meters.

Wheel Loaders Liebherr L 524

Visit Liebherr live at

Technical specs - L 524 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
10.4 t
Standard tyres
17.5 R 25
Bucket width
2.5 m
Bucket capacity
2.1 m³
Bucket capacity min.
2.1 m³
Steering mode
KL
Transport length
6.82 m
Transport width
2.5 m
Transport height
3.2 m
Travel speed
40 km/h
Max. discharge height
2.85 m
Turning radius outside
5.7 m
Model series
L
Engine manuf.
John Deere
Engine type
4045HFL92
Engine power
90 kW
Displacement
4.5 l
Revolutions at max torque
1600 rpm
Emission level
IIIB

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr L 524 FAQ

When was the Liebherr L 524 manufactured?

The Liebherr L 524 was manufactured from 2013 to 2016.

How much does the Liebherr L 524 wheel loader weigh?

The Liebherr L 524 wheel loader weighs 10.4 tons.

What are the transport dimensions of the Liebherr L 524 wheel loader?

The Liebherr L 524 has a transport length of 6.82 meters, a transport width of 2.5 meters, and a transport height of 3.2 meters.

What is the travel speed of the Liebherr L 524 wheel loader?

The Liebherr L 524 wheel loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the Liebherr L 524 wheel loader?

The Liebherr L 524 wheel loader is equipped with standard tyres sized 17.5 R 25.

What are the maneuverability specifications of the Liebherr L 524 wheel loader?

The Liebherr L 524 wheel loader has an outside turning radius of 5.7 meters and features articulated-frame steering.

What is the maximum discharge height of the Liebherr L 524?

The Liebherr L 524 has a maximum discharge height of 2.85 meters.

What are the specifications of the bucket on the Liebherr L 524 wheel loader?

The Liebherr L 524 wheel loader has a bucket capacity of 2.1 cubic meters, a minimum bucket capacity of 2.1 cubic meters, and a bucket width of 2.5 meters.

How much is a Liebherr L 524 Wheel loader (2013u20132016) worth?

The residual value of the Liebherr L 524 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
