L 509 Tele Liebherr L 509 Tele Specifications & Technical Data (2020—2026)

Reliability

The use of ideally matched components and the stable machine design make the telescopic wheel loader extremely powerful and guarantee a long life. Reliable operations are possible in even the toughest conditions. The customer therefore has the machine power available when it is urgently required. The intelligent overload warning system consists of load torque limit and load torque indicator via display. These aids constantly inform the operator about the load situation and stability of the machine. Before the stability limit of the machine is reached in the forward tilting direction, the movements of the working hydraulics slow to a standstill. At the same time, when the maximum lifting load is exceeded, the operator is automatically alerted by visual warnings on the display and an acoustic signal. This means that the operator can work with safety and concentration, which significantly increases productivity.

Maintainability

The most important points for daily maintenance can be reached safely and conveniently from the ground. The entire engine compartment is accessible via just one enclosure. Quick and safe checks save time and money.

Brakes

Wear-free service brake due to hydrostatic driveline, applied to all four wheels and additional dual-circuit brake system, drum brake and wet multi-disc brake located in the front axle. Negative brake system in the front axle acting on the wet multi-disc brakes. The braking system meets the requirements of the ISO 3450.

The Liebherr Telescopic Wheel Loaders

Before operating the vehicle with tyre foam filling or tyre protection chains, please discuss this with the Liebherr-Werk Bischofshofen GmbH.

Attachment Hydraulics

Gear pump to supply the hydraulic and steering systems (via priority valve). Hydraulic oil cooling using thermostatically controlled fan. Suction return line filter in the hydraulic reservoir. Liebherr control lever, electro-proportionally operated, 1st and 2nd additional hydraulic function electro-proportionally controlled optional. Lifting, neutral, lowering. Float position controlled by Liebherr control lever with detent, automatic lift arm position and lowering by Liebherr control lever optional. Tilt back, neutral, dump. Automatic bucket return for tilting back and dumping controlled by Liebherr control lever optional. Telescoping extension and retraction controlled electro-proportionally operated by mini-joystick, stroke limit damping.

Operator’s Cab

Elastic mounted, noise-proof cab. ROPS roll over protection per EN ISO 3471 / EN 474-1. FOPS falling objects protection per EN ISO 3449 / EN 474-1, Cat. II. Operator’s door with 180° opening angle with rigid window, fold-out window on right with 12° gap opener or 180° opening, roof glass panel, roof glass panel windscreen wiper optional, single-pane safety glass ESG, heated rear window ESG, all windows are tinted. Continuously adjustable steering column optional. 5-way adjustable, vibration-damped operator’s seat “standard” (mechanically sprung, adjustable to operator’s weight). Liebherr control lever mounted into the operator’s seat as standard. Fresh/recirculated air mode, cab heating via cooling water, arrangement of the air nozzles ensures quick defrosting or defogging of the windows, electrically heated rear window.
