L 506 Compact Liebherr L 506 Compact Specifications & Technical Data (2022—2026)

The Liebherr L 506 Compact is a wheel loader manufactured since 2022. It has a weight of 4.97 tons and a transport length of 5.395…

The Liebherr L 506 Compact is a wheel loader manufactured since 2022. It has a weight of 4.97 tons and a transport length of 5.395 meters. The bucket capacity ranges from 0.7 to 0.8 cubic meters, with a bucket width of 1.9 meters. The maximum discharge height is 2.505 meters, and it has a travel speed of 20 km/h. The transport width and height are both 1.9 and 2.48 meters respectively. The turning radius outside is 4.37 meters. This construction machine is equipped with a diesel particulate filter and a quick hitch hydr.

Wheel Loaders Liebherr L 506 Compact
Wheel Loaders Liebherr L 506 Compact
Wheel Loaders Liebherr L 506 Compact
Wheel Loaders Liebherr L 506 Compact
Wheel Loaders Liebherr L 506 Compact
Wheel Loaders Liebherr L 506 Compact
Wheel Loaders Liebherr L 506 Compact
Wheel Loaders Liebherr L 506 Compact

Visit Liebherr live at

Technical specs - L 506 Compact Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.97 t
Standard tyres
340/80 R18
Bucket width
1.9 m
Bucket capacity
0.8 m³
Bucket capacity min.
0.7 m³
Bucket capacity max.
0.8 m³
Steering mode
KL
Transport length
5.395 m
Transport width
1.9 m
Transport height
2.48 m
Travel speed
20 km/h
Max. discharge height
2.505 m
Turning radius outside
4.37 m
Model series
L
Engine manuf.
Yanmar
Engine type
4TNV86CHT
Engine power
47.5 kW
Displacement
2.091 l
Revolutions at max torque
1690 rpm
Max. torque
207 Nm
No. of cylinders
4
Cylinder bore x stroke
86x90 mm
Emission level
V

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Liebherr L 506 Compact FAQ

When was the Liebherr L 506 Compact manufactured?

The Liebherr L 506 Compact was first produced in 2022.

How much does the Liebherr L 506 Compact weigh?

The Liebherr L 506 Compact weighs 4.97 tons.

What are the transport dimensions of the Liebherr L 506 Compact wheel loader?

The Liebherr L 506 Compact has a transport length of 5.4 meters, a transport width of 1.9 meters, and a transport height of 2.48 meters.

What is the travel speed of the Liebherr L 506 Compact wheel loader?

The Liebherr L 506 Compact has a travel speed of 20 km/h.

What are the undercarriage specifications of the Liebherr L 506 Compact wheel loader?

The Liebherr L 506 Compact wheel loader is equipped with standard tyres sized 340/80 R18.

What are the maneuverability specifications of the Liebherr L 506 Compact wheel loader?

The Liebherr L 506 Compact has an articulated-frame steering system and an outside turning radius of 4.37 meters.

What is the maximum discharge height of the Liebherr L 506 Compact wheel loader?

The Liebherr L 506 Compact has a maximum discharge height of 2.51 meters.

What are the specifications of the bucket on the Liebherr L 506 Compact wheel loader?

The Liebherr L 506 Compact wheel loader has a bucket with a capacity ranging from 0.7 to 0.8 cubic meters and a width of 1.9 meters.

How much is a Liebherr L 506 Compact Wheel loader (2022u20132025) worth?

The residual value of the Liebherr L 506 Compact depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
