8180 Kramer 8180 Specifications & Technical Data (2020—2026)

The Kramer 8180 is a wheel loader manufactured since 2020. It has a weight of 11.05 tons and a transport length of 6.55 meters. Th…

The Kramer 8180 is a wheel loader manufactured since 2020. It has a weight of 11.05 tons and a transport length of 6.55 meters. The bucket capacity ranges from 1.35 to 3.5 cubic meters, with a bucket width of 2.5 meters. The maximum discharge height is 2.695 meters. It has a travel speed of 20 km/h and a transport width of 2.5 meters. The transport height is 3.01 meters, and the turning radius outside is 3.865 meters. Special equipment includes air conditioning, a diesel particulate filter, a quick hitch hydraulic mechanism, and a swing loader.

8180

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - 8180 Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 11.05 t

Standard tyres: 500/70R24

Bucket width: 2.5 m

Bucket capacity: 1.8 m³

Bucket capacity min.: 1.35 m³

Bucket capacity max.: 3.5 m³

Steering mode: AL

Transport length: 6.55 m

Transport width: 2.5 m

Transport height: 3.01 m

Travel speed: 20 km/h

Max. discharge height: 2.695 m

Turning radius outside: 3.865 m

Lifting force: 65 kN

Engine manuf.: Deutz

Engine type: TCD4.1 L4

Engine power: 115 kW

Displacement: 4.038 l

Max. torque: 609/1600 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: model series, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: Yes
telescopic: No
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Kramer 8180 FAQ

When was the Kramer 8180 manufactured?

The Kramer 8180 was first produced in 2020.

How much does the Kramer 8180 wheel loader weigh?

The Kramer 8180 wheel loader weighs 11.05 tons.

What are the transport dimensions of the Kramer 8180 wheel loader?

The Kramer 8180 has a transport length of 6.55 meters, a transport width of 2.5 meters, and a transport height of 3.01 meters.

What is the travel speed of the Kramer 8180 wheel loader?

The Kramer 8180 wheel loader has a travel speed of 20 km/h.

What is the undercarriage specification of the Kramer 8180 wheel loader?

The Kramer 8180 wheel loader has standard tyres sized 500/70R24.

What are the maneuverability specifications of the Kramer 8180 wheel loader?

The Kramer 8180 wheel loader has an outside turning radius of 3.865 meters and features all-wheel steering.

What is the power rating of the Kramer 8180 wheel loader?

The source data does not provide power rating information for the Kramer 8180 wheel loader.

What is the material handling capacity of the Kramer 8180 in terms of discharge height?

The Kramer 8180 has a maximum discharge height of 2.7 meters.

What are the specifications of the primary work tool bucket on the Kramer 8180 wheel loader?

The Kramer 8180 wheel loader has a bucket with a capacity ranging from 1.35 to 3.5 cubic meters, a standard capacity of 1.8 cubic meters, and a width of 2.5 meters.

How much is a Kramer 8180 Wheel loader (2020u20132025) worth?

The residual value of the Kramer 8180 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
