8145T Kramer 8145T Specifications & Technical Data (2019—2026)

The Kramer 8145T is a wheel loader manufactured by Kramer since 2019. It has a weight of 11.17 tons and a transport length of 7.02…

The Kramer 8145T is a wheel loader manufactured by Kramer since 2019. It has a weight of 11.17 tons and a transport length of 7.02 meters. The bucket capacity is 1.45 cubic meters with a width of 2.5 meters. The maximum discharge height is 4.47 meters and it has a travel speed of 20 km/h. The transport width and height are both 2.5 and 3.01 meters respectively. It has a lifting force of 50 kN and a turning radius outside of 3.865 meters. The bucket capacity ranges from a minimum of 1.35 cubic meters to a maximum of 3.5 cubic meters. It is equipped with special features such as air conditioning, a diesel particulate filter, and a quick hitch hydraulic telescopic system.

Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T
Wheel Loaders Kramer 8145T

Technical specs - 8145T Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
11.17 t
Standard tyres
500/70R24
Bucket width
2.5 m
Bucket capacity
1.45 m³
Bucket capacity min.
1.35 m³
Bucket capacity max.
3.5 m³
Steering mode
AL
Transport length
7.02 m
Transport width
2.5 m
Transport height
3.01 m
Travel speed
20 km/h
Max. discharge height
4.47 m
Turning radius outside
3.865 m
Lifting force
50 kN
Engine manuf.
Deutz
Engine type
TCD 3.6
Engine power
100 kW
Displacement
3.621 l
Max. torque
500/1600 Nm
No. of cylinders
4
Emission level
V

More technical details, like: model series, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
Yes
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Kramer 8145T FAQ

When was the Kramer 8145T manufactured?

The Kramer 8145T was first produced in 2019.

How much does the Kramer 8145T wheel loader weigh?

The Kramer 8145T wheel loader weighs 11.17 tons.

What are the transport dimensions of the Kramer 8145T wheel loader?

The Kramer 8145T has a transport length of 7.02 meters, a transport width of 2.5 meters, and a transport height of 3.01 meters.

What is the travel speed of the Kramer 8145T wheel loader?

The Kramer 8145T has a travel speed of 20 km/h.

What is the standard tyre size of the Kramer 8145T wheel loader?

The Kramer 8145T is equipped with standard tyres sized 500/70R24.

What are the maneuverability specifications of the Kramer 8145T wheel loader?

The Kramer 8145T has an outside turning radius of 3.865 meters and features all-wheel steering.

What is the power rating of the Kramer 8145T wheel loader?

The power rating of the Kramer 8145T wheel loader is not provided in the available data.

What is the maximum discharge height of the Kramer 8145T?

The Kramer 8145T has a maximum discharge height of 4.47 meters.

What are the bucket specifications of the Kramer 8145T wheel loader?

The Kramer 8145T wheel loader has a bucket capacity of 1.45 cubic meters, with a maximum capacity of 3.5 cubic meters, a minimum capacity of 1.35 cubic meters, and a bucket width of 2.5 meters.

How much is a Kramer 8145T Wheel loader (2019u20132025) worth?

The residual value of the Kramer 8145T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
