750 T Kramer 750 T Specifications & Technical Data (2009—2015)

Model rating: 9,00 / 10

The Kramer 750 T is a wheel loader manufactured from 2009 to 2015. It has a weight of 5.1 tons and a transport length of 5.5 meter…

The Kramer 750 T is a wheel loader manufactured from 2009 to 2015. It has a weight of 5.1 tons and a transport length of 5.5 meters. The bucket capacity is 0.75 cubic meters, with a bucket width of 1.75 meters. The maximum discharge height is 4 meters, and it has a travel speed of 20 km/h. The transport width is 1.72 meters, and the transport height is 2.58 meters. It has a lifting force of 30 kN and a turning radius outside of 2.55 meters. Special equipment includes a quick hitch mechanism and telescopic capabilities.

750 T

Years of manufacture: 2009—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 750 T Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.1 t

Standard tyres: 12.5-18

Bucket width: 1.75 m

Bucket capacity: 0.75 m³

Bucket capacity min.: 0.75 m³

Steering mode: AL

Transport length: 5.5 m

Transport width: 1.72 m

Transport height: 2.58 m

Travel speed: 20 km/h

Max. discharge height: 4 m

Turning radius outside: 2.55 m

Lifting force: 30 kN

Engine manuf.: Deutz

Engine type: F4M2011

Engine power: 44 kW

Displacement: 3.619 l

Revolutions at max torque: 1700 rpm

More technical details, like: bucket capacity max., model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Kramer 750 T FAQ

When was the Kramer 750 T manufactured?

The Kramer 750 T was manufactured from 2009 to 2015.

How much does the Kramer 750 T wheel loader weigh?

The Kramer 750 T wheel loader weighs 5.1 tons.

What are the transport dimensions of the Kramer 750 T wheel loader?

The Kramer 750 T has a transport length of 5.5 meters, a transport width of 1.72 meters, and a transport height of 2.58 meters.

What is the travel speed of the Kramer 750 T wheel loader?

The Kramer 750 T has a travel speed of 20 km/h.

What are the undercarriage specifications of the Kramer 750 T wheel loader?

The Kramer 750 T wheel loader is equipped with standard tyres sized 12.5-18.

What are the maneuverability specifications of the Kramer 750 T wheel loader?

The Kramer 750 T wheel loader has an outside turning radius of 2.55 meters and features all-wheel steering.

What is the lifting force of the Kramer 750 T wheel loader?

The Kramer 750 T wheel loader has a lifting force of 30 kN.

What is the maximum discharge height of the Kramer 750 T wheel loader?

The Kramer 750 T has a maximum discharge height of 4 meters.

What are the specifications of the primary work tool (bucket) on the Kramer 750 T wheel loader?

The Kramer 750 T wheel loader has a bucket with a capacity of 0.75 cubic meters and a width of 1.75 meters.
