WLK9 Kobelco WLK9 Specifications & Technical Data (1993—2026)
Visit Kobelco live at
.jpg){kind=logo}
Technical specs - WLK9 Kobelco
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 5.289 t
- Standard tyres
- 405/70 R20
- Bucket width
- 2.1 m
- Bucket capacity
- 1 m³
- Bucket capacity max.
- 1 m³
- Transport width
- 2.11 m
- Transport height
- 2.74 m
- Travel speed
- 20 km/h
- Turning radius outside
- 4.45 m
- Engine manuf.
- Deutz
- Engine type
- BF4L1011
- Engine power
- 50 kW
- Displacement
- 2.7 l
- No. of cylinders
- 4
More technical details, like: bucket capacity min., steering mode, transport length, max. discharge height, lifting force, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
No
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
Kobelco WLK9 FAQ
How much does the Kobelco WLK9 wheel loader weigh?
What are the transport dimensions of the Kobelco WLK9 wheel loader?
What is the travel speed of the Kobelco WLK9 wheel loader?
What are the undercarriage specifications of the Kobelco WLK9 wheel loader?
What is the turning radius of the Kobelco WLK9 wheel loader?
What are the specifications of the bucket on the Kobelco WLK9 wheel loader?
