824K-II John Deere Construction 824K-II Specifications & Technical Data (2015—2019)

The John Deere Construction 824K-II is a wheel loader manufactured from 2015 to 2019. It has a weight of 26.8 tons and a transport…

The John Deere Construction 824K-II is a wheel loader manufactured from 2015 to 2019. It has a weight of 26.8 tons and a transport length of 9.28 meters. The bucket width is 3.27 meters, and it has a maximum discharge height of 3.19 meters. The travel speed of this machine is 40 km/h. It has a transport width of 3.084 meters and a transport height of 3.55 meters. The turning radius outside is 5.92 meters. The bucket capacity ranges from a minimum of 4 cubic meters to a maximum of 4.6 cubic meters. It is equipped with air conditioning.

824K-II

Years of manufacture: 2015—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 824K-II John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 26.8 t

Standard tyres: 26.5 R25

Bucket width: 3.27 m

Bucket capacity min.: 4 m³

Bucket capacity max.: 4.6 m³

Steering mode: AL

Transport length: 9.28 m

Transport width: 3.084 m

Transport height: 3.55 m

Travel speed: 40 km/h

Max. discharge height: 3.19 m

Turning radius outside: 5.92 m

Model series: K

Engine manuf.: John Deere

Engine type: PowerTech Plus 6135H

Engine power: 248 kW

Displacement: 13.5 l

Revolutions at max torque: 1600 rpm

Max. torque: 1619/900 Nm

No. of cylinders: 6

Emission level: Tier 3/EU IIIA

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

John Deere Construction 824K-II FAQ

When was the John Deere Construction 824K-II manufactured?

The John Deere Construction 824K-II was manufactured from 2015 to 2019.

How much does the John Deere Construction 824K-II weigh?

The John Deere Construction 824K-II weighs 26.8 tons.

What are the transport dimensions of the John Deere Construction 824K-II wheel loader?

The John Deere Construction 824K-II has a transport length of 9.28 meters, a transport width of 3.08 meters, and a transport height of 3.55 meters.

What is the travel speed of the John Deere Construction 824K-II wheel loader?

The John Deere Construction 824K-II has a travel speed of 40 km/h.

What are the undercarriage specifications of the John Deere Construction 824K-II wheel loader?

The John Deere Construction 824K-II wheel loader is equipped with standard tyres sized 26.5 R25.

What are the maneuverability specifications of the John Deere Construction 824K-II wheel loader?

The John Deere Construction 824K-II has an outside turning radius of 5.92 meters and features all-wheel steering.

What is the maximum discharge height of the John Deere Construction 824K-II wheel loader?

The John Deere Construction 824K-II wheel loader has a maximum discharge height of 3.19 meters.

What are the specifications of the bucket on the John Deere Construction 824K-II wheel loader?

The John Deere Construction 824K-II wheel loader has a bucket with a width of 3.27 meters and a capacity ranging from 4 to 4.6 cubic meters.
