624 J TC John Deere Construction 624 J TC Specifications & Technical Data (2004—2021)

The John Deere Construction 624 J TC is a wheel loader manufactured from 2004 to 2021. It has a weight of 13.986 tons and a transp…

The John Deere Construction 624 J TC is a wheel loader manufactured from 2004 to 2021. It has a weight of 13.986 tons and a transport length of 7.63 meters. The bucket width measures 2.69 meters, and it has a travel speed of 37.6 km/h. The transport height is 3.81 meters, and the turning radius outside is 5.18 meters. The maximum bucket capacity is 2.7 cubic meters, while the minimum capacity is 2.3 cubic meters.

624 J TC

Years of manufacture: 2004—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 624 J TC John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 13.986 t

Standard tyres: 20.5 R 25

Bucket width: 2.69 m

Bucket capacity min.: 2.3 m³

Bucket capacity max.: 2.7 m³

Transport length: 7.63 m

Transport height: 3.81 m

Travel speed: 37.6 km/h

Turning radius outside: 5.18 m

Model series: J

Engine manuf.: John Deere

Engine type: 6068H

Engine power: 119 kW

Displacement: 6.8 l

Max. torque: 780 Nm

No. of cylinders: 6

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

624 J TC John Deere Construction Specification for North America (FR)

John Deere Construction 624 J TC FAQ

When was the John Deere Construction 624 J TC manufactured?

The John Deere Construction 624 J TC was manufactured from 2004 to 2021.

How much does the John Deere Construction 624 J TC weigh?

The John Deere Construction 624 J TC weighs 13.99 tons.

What are the transport dimensions of the John Deere Construction 624 J TC wheel loader?

The John Deere Construction 624 J TC has a transport length of 7.63 meters and a transport height of 3.81 meters.

What is the travel speed of the John Deere Construction 624 J TC wheel loader?

The John Deere Construction 624 J TC has a travel speed of 37.6 km/h.

What are the standard tyre specifications of the John Deere Construction 624 J TC?

The John Deere Construction 624 J TC has standard tyres sized 20.5 R 25.

What is the outside turning radius of the John Deere Construction 624 J TC wheel loader?

The John Deere Construction 624 J TC has an outside turning radius of 5.18 meters.

What are the bucket specifications of the John Deere Construction 624 J TC wheel loader?

The John Deere Construction 624 J TC has a bucket width of 2.69 meters with a capacity ranging from 2.3 to 2.7 cubic meters.

How much is a John Deere Construction 624 J TC Wheel loader (2004u20132021) worth?

The residual value of the John Deere Construction 624 J TC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
