544K-II John Deere Construction 544K-II Specifications & Technical Data (2017—2019)

The John Deere Construction 544K-II is a wheel loader manufactured from 2017 to 2019. It has a weight of 13.22 tons and a transpor…

The John Deere Construction 544K-II is a wheel loader manufactured from 2017 to 2019. It has a weight of 13.22 tons and a transport length of 7.43 meters. The bucket width is 2.54 meters and the maximum discharge height is 2.76 meters. It has a travel speed of 40 km/h and a transport width of 2.55 meters. The transport height is 3.24 meters, and the turning radius outside is 5 meters. The bucket capacity ranges from 2 to 4 cubic meters. Special equipment includes air conditioning.

Wheel Loaders John Deere Construction 544K-II

544K-II

Years of manufacture: 2017—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 544K-II John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 13.22 t

Standard tyres: 20.5 R25

Bucket width: 2.54 m

Bucket capacity min.: 2 m³

Bucket capacity max.: 4 m³

Steering mode: AL

Transport length: 7.43 m

Transport width: 2.55 m

Transport height: 3.24 m

Travel speed: 40 km/h

Max. discharge height: 2.76 m

Turning radius outside: 5 m

Model series: K

Engine manuf.: John Deere

Engine type: PowerTech PVS 6068

Engine power: 121 kW

Displacement: 6.8 l

Revolutions at max torque: 1800 rpm

Max. torque: 683/1100 Nm

No. of cylinders: 6

Emission level: Tier 4f/EU IV

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

John Deere Construction 544K-II FAQ

When was the John Deere Construction 544K-II manufactured?

The John Deere Construction 544K-II was manufactured from 2017 to 2019.

How much does the John Deere Construction 544K-II weigh?

The John Deere Construction 544K-II weighs 13.22 tons.

What are the transport dimensions of the John Deere Construction 544K-II wheel loader?

The John Deere Construction 544K-II has a transport length of 7.43 meters, a transport width of 2.55 meters, and a transport height of 3.24 meters.

What is the travel speed of the John Deere Construction 544K-II wheel loader?

The John Deere Construction 544K-II has a travel speed of 40 km/h.

What is the standard tyre size of the John Deere Construction 544K-II undercarriage?

The John Deere Construction 544K-II has standard tyres sized 20.5 R25.

What are the maneuverability specifications of the John Deere Construction 544K-II wheel loader?

The John Deere Construction 544K-II has an outside turning radius of 5 meters and features all-wheel steering.

What is the maximum discharge height of the John Deere Construction 544K-II wheel loader?

The John Deere Construction 544K-II wheel loader has a maximum discharge height of 2.76 meters.

What are the bucket specifications of the John Deere Construction 544K-II wheel loader?

The John Deere Construction 544K-II wheel loader has a bucket width of 2.54 meters with a capacity ranging from 2 to 4 cubic meters.

How much is a John Deere Construction 544K-II Wheel loader (2017u20132019) worth?

The residual value of the John Deere Construction 544K-II depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
