TM420 S JCB TM420 S Specifications & Technical Data (2020—2026)

The JCB TM420 S is a wheel loader manufactured by JCB since 2020. It has a weight of 9.8 tons and a transport length of 7 meters. …

The JCB TM420 S is a wheel loader manufactured by JCB since 2020. It has a weight of 9.8 tons and a transport length of 7 meters. The bucket capacity is 1.6 cubic meters, with a bucket width of 2.35 meters. The travel speed of this machine is 40 km/h. It has a transport width and height of 2.35 meters and 2.8 meters respectively. The turning radius outside is 5.6 meters. Special equipment includes air conditioning, a diesel particulate filter, and a quick hitch hydraulic system. Additionally, it is equipped with a telescopic feature.

Wheel Loaders JCB TM420 S

Visit JCB live at

Technical specs - TM420 S JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.8 t
Standard tyres
BIBLOAD 480/80R26
Bucket width
2.35 m
Bucket capacity
1.6 m³
Steering mode
KL
Transport length
7 m
Transport width
2.35 m
Transport height
2.8 m
Travel speed
40 km/h
Turning radius outside
5.6 m
Model series
TM
Engine manuf.
JCB
Engine type
EcoMax
Engine power
129 kW
Displacement
4.8 l
Max. torque
690 Nm
No. of cylinders
4
Cylinder bore x stroke
106x139 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., max. discharge height, lifting force, dimension lxwxh, revolutions at max torque are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
Yes
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

JCB TM420 S FAQ

When was the JCB TM420 S manufactured?

The JCB TM420 S was first produced in 2020.

How much does the JCB TM420 S wheel loader weigh?

The JCB TM420 S wheel loader weighs 9.8 tons.

What are the transport dimensions of the JCB TM420 S wheel loader?

The JCB TM420 S has a transport length of 7 meters, a transport width of 2.35 meters, and a transport height of 2.8 meters.

What is the travel speed of the JCB TM420 S wheel loader?

The JCB TM420 S has a travel speed of 40 km/h.

What are the undercarriage specifications of the JCB TM420 S wheel loader?

The JCB TM420 S is equipped with standard tyres sized XMCL 480/80R26.

What are the maneuverability specifications of the JCB TM420 S wheel loader?

The JCB TM420 S has an articulated-frame steering system and an outside turning radius of 5.6 meters.

What are the bucket specifications of the JCB TM420 S wheel loader?

The JCB TM420 S has a bucket capacity of 1.6 cubic meters and a bucket width of 2.35 meters.

How much is a JCB TM420 S Wheel loader (2020u20132025) worth?

The residual value of the JCB TM420 S depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
